>>>>>型号:DS200DMCBG1AKG 处理器板 表面贴装复位开关
【功能描述】
DS200DMCBG1AKG技术规格
制造者GE通用电气
系列EX2000型
零件编号DS200DMCBG1AKG
功能描述IOS DUP处理器板DS200DMCBG1AKG是由值得信赖的工业零售商通用电气生产的GE IOS处理器板。互联网上教学手册材料的相对稀缺性使得它很难区分特定的制造商和系列，但
硬件提示和规格
与许多GE工业系统Fanuc产品一样，GE IOS DUP处理器板DS200DMCBG1AKG在许多重要的硬件规格上都是独一无二的。基于彻底的目视检查，该DMCB模型包含几个独特的元素，包括：
三个26针连接器
一个40针连接器
2个LED指示灯
表面贴装复位开关
共19个跳线
安装程序可以使用DS200DMCBG1AKG上的跳线来更改电路板的行为。出厂时随附的原装电路板随附的手册描述了跳线以及它们如何改变电路板的行为，尽管如前所述，本手册的在线可用性相对有限。虽然此DS200 DMCB的底板上确实存在可定制的硬件跳线，但并非所有跳线都可以由安装人员或合格的服务人员移动。此模块底板上的一些跳线是硬接线跳线，仅用于制造工厂的测试目的。GE Fanuc或原始电路板随附的其他系列手册也将识别这些跳线。
虽然该型号在互联网上的手册信息通常很少，但该电路板底板上的一系列工厂发布的标签可以揭示其他重要的硬件规格.例如，该DS200DMCBG1AKG型号在电路板顶部贴有“IOS主控”功能描述。除了这个最初的一般描述性标签外，该型号的DMCG PCB还贴有各种标签，包括C-ESS、V 5和美国通用电气，以及DMCG表面配备的数百个继电器和众多插头的标准行业标签。
>>>>>型号:DS200DMCBG1AKG 处理器板 表面贴装复位开关
【英文介绍】
DS200DMCBG1AKG Technical specifications
Manufacturer GE General Electric
Series EX2000
Part number DS200DMCBG1AKG
The IOS DUP processor board DS200DMCBG1AKG is a GE IOS processor board manufactured by trusted industrial retailer General Electric. The relative scarcity of instructional manual materials on the Internet makes it difficult to distinguish between specific manufacturers and series, however
Hardware tips and specifications
Like many GE Industrial Systems Fanuc products, the GE IOS DUP processor board DS200DMCBG1AKG is unique in a number of important hardware specifications. Based on a thorough visual inspection, the DMCB model contains several unique elements, including:
Three 26-pin connectors
A 40 pin connector
2 LED indicators
Surface mount reset switch
A total of 19 jumpers
The installer can use jumpers on the DS200DMCBG1AKG to change the behavior of the board. The manual that comes with the original board shipped with the factory describes the jumpers and how they change the behavior of the board, although as mentioned earlier, the online availability of this manual is relatively limited. While customizable hardware jumpers do exist on the baseboard of this DS200 DMCB, not all of them can be moved by installers or qualified service personnel. Some of the jumpers on the baseboard of this module are hardwired jumpers and are only used for testing purposes in manufacturing plants. These jumpers will also be identified in the GE Fanuc or other series manuals that came with the original circuit board.
While manual information for this model on the Internet is usually sparse, a series of factory-issued labels on the board's backboard can reveal other important hardware specifications. For example, the DS200DMCBG1AKG model has the "IOS Master" function description posted on the top of the board. In addition to this initial general descriptive label, the DMCG PCB for this model is also labeled with various labels, including C-ESS, V 5, and US General Electric, as well as the standard industry label for hundreds of relays and numerous plugs equipped with the DMCG surface.
