【功能描述】
DS200DCFBG1BGBGBLC是通用电气为Mark V系列可选板和替换板设计的电源板。该系列的成员与许多GE品牌的励磁机和驱动器交叉兼容。DC2000、AC2000、CB2000、ME2000和FC2000的驱动器都可以接受此电源板。此卡为其安装的驱动器提供系统控制级电源,并为机柜风扇提供电力。该板的源交流输入额定电压范围为38至115 VAC。伴随此VAC的频率范围为0至500 kHz,具体取决于输入电压的强度。
DS200DCFBG1BGBGBLC包含许多复杂的电路系统,旨在为大部分驱动器供电。该卡包括交流和直流监控电路、控制电平电源电路、电机励磁电源电路和驱动电路。用户可以在卡上配置12个跳线和7个DIP开关,以满足任何外部要求。电路板状态通过板载指示器传达给用户。卡内置两个LED指示灯和一个霓虹灯指示灯,为用户提供重要的诊断和状态信息。电路板的三个保险丝受到保护,确保中断或浪涌不会中断电流。确保使用集成到电路板中的五个测试点定期监控电压水平。
必须遵循DS200DCFBG1BGBGBLC和驱动器提供的安装参数。这些准则将确保电路板及其安装的系统按预期运行。有关接线和安装指南,请参阅系列手册以及设备数据表。Mark V系列所有主板的技术支持最初由制造商通用电气提供。
DS200DCFBG1BGBLC是电源板Mark V系列的一个特定型号。电源板是电子设备中用于提供电能的组件,而Mark V系列可能是指该电源板的系列名称。DS200DCFBG1BGBLC这个型号可能是该系列中的一款特定产品,具有特定的规格和功能。
为了获取更详细的信息,您可能需要查阅制造商的官方文档或联系制造商的技术支持部门。此外,您也可以在专业论坛或社区中寻求其他用户的帮助和建议,他们可能会提供有关该型号电源板的更多信息或使用经验。
>>>>>型号:DS200DCFBG1BLC 替换板设计的电源板 驱动器交叉兼容
【英文介绍】
DS200CTBAG1ADD GE Mark V terminal board
DS200CTBAG1ADD is a terminal board designed for GE Mark V Speedtronic systems. The Speedtronic family was created by General Electric to control large and small gas and steam turbine systems. MKV can be designed with simplex or TMR/ triple modular redundancy architecture to meet the needs of interconnected turbine systems. The boards are no longer manufactured and distributed by GE, but can be purchased as fully tested and refurbished models through AX Control.
The DS200CTBAG1ADD is a long, narrow circuit board with only a few types of components. It drilled holes in each corner and long side to allow for the installation of hardware and other connections. Two of the holes are surrounded by conductive material. The board is marked with an identification code, including the board ID number and the company logo.
DS200CTBAG1ADD is an analog terminal module. It is usually located in the R5> Inside the kernel. The board has multiple connectors, including two COREBUS connectors (JAI and JAJ). The DS200CTBAG1ADD has two double-stacked terminal blocks located at the edge of a longboard with multiple connectors on each terminal block. There are 5 vertical pin cable connectors, 2 vertical pin connector connectors, and a 9-pin male serial connector.
Other components on the DS200CTBAG1ADD include a resistor network array, relays, transistors, more than two dozen metal oxide varistors (MOV), a dozen jumper switches, and many capacitors and resistors. For more information, see GE's original technical support offering.
