IS200TRLYH1D |5SHY5045L0020|燃气轮机控制单元|

IS200TRLYH1D 是由通用电气（General Electric, GE）生产的一款电路板，属于燃气轮机控制系统中的 VIe 系列产品。这个板卡是燃气轮机控制单元的一个关键组件，主要功能是接收和处理来自各种传感器的信号，根据预设的控制逻辑对燃气轮机进行精确的控制和调节 。

该电路板具有以下特点：

集成了多种电子元件，包括集成电路、电阻器、电容器、扼流圈等 。

配备了多个连接器，例如 37 针连接器，用于与其他电路板或设备进行连接和数据传输 。

设计用于安装在变频器的板柜中，具有专用的硬件组件和规格 。

可能与 Mark VIe 或 Mark VleS 控制系统中的后备保护功能相关联，通过接线到继电器板形成保护 。

IS200TRLYH1D 板卡作为具有电磁完整性传感的继电器输出端子板，具有六个插入式磁继电器。这些电路是 C 型触点输出，通过熔断和供电来驱动外部螺线管。坏的螺线管可以通过在每个继电器电路上提供的特殊反馈来检测。该板卡与 TRLYH1B 板类似，但只有六个继电器，专为 24/125V 直流应用而设计。继电器不能配置为干接点使用，输入继电器线圈监控已被移除，通常由 VCRC 或 VCCC 单板控制，支持 TMR（三模冗余）或单工应用程序 。

此外，该板卡的规格包括：

额定电压：125V DC

尺寸：17.8 厘米宽 x 33.02 厘米高

工作温度范围：-30 至 +65°C

电源消耗：4W

内部操作系统：QNX

配置软件：ToolboxST

The IS200TRLYH1D is a circuit board manufactured by General Electric (GE) as part of the VIe family of gas turbine control systems. This board is a key component of the gas turbine control unit, the main function is to receive and process signals from various sensors, according to the preset control logic of the gas turbine precise control and regulation.

The board has the following features:

It integrates a variety of electronic components, including integrated circuits, resistors, capacitors, chokes, etc.

It is equipped with multiple connectors, such as 37-pin connectors, for connection and data transfer with other boards or devices.

Designed to be installed in the board cabinet of the inverter, with dedicated hardware components and specifications.

May be associated with the backup protection function in the Mark VIe or Mark VleS control system, which is protected by wiring to the relay board.

The IS200TRLYH1D board is a relay output terminal board with electromagnetic integrity sensing with six plug-in magnetic relays. These circuits are C-contact outputs that drive the external solenoid by fusing and supplying power. Bad solenoids can be detected by special feedback provided on each relay circuit. The board is similar to the TRLYH1B board, but has only six relays and is designed for 24/125V DC applications. The relay cannot be configured for dry contact use, the input relay coil monitoring has been removed and is usually controlled by a VCRC or VCCC board, supporting TMR (three-mode redundancy) or simplex applications.

In addition, the specifications of the board include:

Rated voltage: 125V DC

Dimensions: 17.8 cm wide x 33.02 cm high

Operating temperature range: -30 to +65°C

Power consumption: 4W

Internal operating system: QNX

Configuration software: ToolboxST
