>>>>>型号:IS200TREGH1BEC 保护终端板 涡轮机控制装置
【功能描述】
通用电气 （GE） 开发了iS200TREGH1BEC 保护终端板，作为 Mark VI 系列的一个组件，用于燃气/蒸汽轮机管理和自动化。IS200TREGH1BEC是印刷电路板或PCB的一个版本。Mark VI 系列的 IS200TREGH1BEC 和其他组件是更大的 Mark 系列涡轮机控制装置的一部分。
IS200TREGH1BEC PCB是矩形的。IS200TREGH1BEC上最突出的组件是两 （2） 个接线端子和两 （2） 个继电器或接触器。接线端子是黑色的，尺寸很大。它们垂直放置在IS200TREGH1BEC的左边缘。IS200TREGH1BEC上的继电器在IS200TREGH1BEC顶部的中心垂直配对。这些继电器大多是红色的，它们的顶部有黄色和黑色的部分。紧挨着左侧这些继电器的是两 （2） 个红色圆形 MOV 或金属氧化物压敏电阻。整个IS200TREGH1BEC中都有几个小尺寸的黄色常亮电容器，主要位于电路板的下半部分。IS200TREGH1BEC的右边缘衬有三 （3） 个中型插孔连接器端口，名称为 JZ1、JY1 和 JX1。这些连接器端口中多了三 （3） 个，它们比其他连接器端口小（大约是其他连接器的一半），已排在这些其他连接器端口的左侧。较小的连接器端口已由名称 JZ5、JY5 和 JX5 标识。三 （3） 个黑色可变电阻器或电位计位于IS200TREGH1BEC的右上方。
>>>>>型号:IS200TREGH1BEC 保护终端板 涡轮机控制装置
【英文介绍】
General Electric (GE) has developed the iS200TREGH1BEC protected terminal Board as a component of the Mark VI series for gas/steam turbine management and automation. IS200TREGH1BEC is a version of a printed circuit board or PCB. The IS200TREGH1BEC and other components of the Mark VI series are part of a larger Mark series turbine control unit.
IS200TREGH1BEC PCB is rectangular. The most prominent components on the IS200TREGH1BEC are the two (2) terminals and two (2) relays or contactors. The terminals are black and large. They are placed vertically on the left edge of the IS200TREGH1BEC. The relays on the IS200TREGH1BEC are vertically paired at the center of the top of the IS200TREGH1BEC. Most of these relays are red, and they have yellow and black sections on top. Immediately next to these relays on the left are two (2) red round MOV or metal oxide varistors. Throughout the IS200TREGH1BEC there are several small sized yellow steady on capacitors, mainly located in the bottom half of the circuit board. The right edge of the IS200TREGH1BEC is lined with three (3) medium jack connector ports, named JZ1, JY1 and JX1. There are three (3) more of these connector ports, which are smaller than the other connector ports (about half the size of the other connector ports) and have been lined up to the left of these other connector ports. Smaller connector ports have been identified by the names JZ5, JY5, and JX5. Three (3) black variable resistors or potentiometers are located on the upper right of the IS200TREGH1BEC.
