【功能描述】
IS200TREAH2AED是一个端子板，与Mark VI Speedtronic涡轮机控制系统中的涡轮机保护模块（VPRO）相关联。Mark VI可以设置为单工或三重模块化冗余编队，使其能够控制、保护和监控各种尺寸的涡轮机系统。
该IS200TREAH2AED用于为每个涡轮机保护模块提供独立的速度拾取器。然后，该模块会高速处理它们。IS200TREAH2AED板还将线路电压和发电机电压输入扇出到每个涡轮机保护模块以实现同步，并接受轴速信号以提供紧急超速保护。
该IS200TREAH2AED由三个大型d-shell连接器和三个较小的d-shell连接器组成。在另一侧，电路板有两个端子排，每个端子带有两条螺钉连接线。在两者之间，该板有两个变压器、两个金属氧化物压敏电阻、跳线开关、集成电路、电阻器、电感器、电容器和二极管。该板沿边缘和角落成型，并且在板体内也有几个切口。它带有多个代码和标记以及条形码。一些工厂制造的孔由感应材料环绕。
