IC697CPX772  |  高性能分布式控制系统模 | 以太网接口

　　产品说明: GE IC697CPX772 DCSModule是一款高性能分布式控制系统模

　　块，专为工业自动化应用而设计。它为各种工艺和设备提供可靠、高效的控制能

　　力。

　　产品参数:

　　输入电压:24vdc

　　输出电压:5vdc

　　一通信接口:

　　-工作温度:-40℃℃~ 70℃℃

　　外形尺寸:150mmx100mm x50mm

　　该IC697CPX772是艾默生自动化 90-70 系列可编程逻辑控制器 (PLC) 系列中的中央处理器 (CPU) 模块。该模块专门带有多个通信接口，一 (1) 个 RJ11 串行通信接口和两 (2) 个 9 针 D 壳 RS485 通信端口。该处理器支持 SNP 从站、无断 SNP(从站)、SNPX 和 RTU 串行协议。

　　IC697CPX772 该处理器具有内置 512 KB 随机存取存储器 (RAM) 和 256 KB 非易失性闪存。该处理器支持浮点计算，浮点计算是实际计算和事务中使用的数据格式，因为浮点数学支持十进制值。它可以容纳高达 2K 的离散输入和任意组合的离散输出以及 8K 字的模拟输入和输出数据。

　　IC697CPX772 该处理器配备 80486DX4 微处理器，时钟速度为 96 MHz。对于 Bollean 执行，每个布尔指令的执行速度为 0.4 微秒。它还配备了一个电池供电的实时时钟 (RTC)，精度为每天 +/- 3.5 秒，最大和经过的时间时钟精度为 +/- 0.1%。该模块的锂电池的目录号为 IC697ACC701，在 5 度温度下运行时保质期为 20 年，内存保留期为 6 个月。该IC697CPX772的电流消耗为 3.1 A，工作温度为 0-60 摄氏度。

　　Product Description: GE IC697CPX772 DCSModule is a high-performance distributed control system module

　　Block, designed for industrial automation applications. It provides reliable and efficient control for a variety of processes and equipment

　　Force.

　　Product parameters:

　　Input voltage :24vdc

　　Output voltage :5vdc

　　Communication interface: Ethernet

　　- Operating temperature :-40 ° C ~ 70 ° C

　　Dimensions :150mmx100mm x50mm

　　The IC697CPX772 is a central processing unit (CPU) module in Emerson Automation's 90-70 series Programmable Logic Controller (PLC) family. The module is specially equipped with multiple communication interfaces, one (1) RJ11 serial communication interface and two (2) 9-pin D-shell RS485 communication ports. The processor supports SNP slave, interruptionless SNP (slave), SNPX, and RTU serial protocols.

　　IC697CPX772 This processor has 512 KB of built-in random access memory (RAM) and 256 KB of non-volatile flash memory. The processor supports floating-point computation, which is the data format used in actual calculations and transactions, because floating-point mathematics supports decimal values. It can accommodate up to 2K discrete inputs and any combination of discrete outputs as well as 8K words of analog input and output data.

　　IC697CPX772 The processor is equipped with an 80486DX4 microprocessor with a clock speed of 96 MHz. For Bollean execution, each Boolean instruction is executed at 0.4 microseconds. It also comes with a battery-powered real-time clock (RTC) with an accuracy of +/- 3.5 seconds per day and a maximum and elapsed time clock accuracy of +/- 0.1%. The module's lithium battery, catalog number IC697ACC701, has a shelf life of 20 years when operating at 5 degrees and a memory retention period of 6 months. The IC697CPX772 has a current consumption of 3.1A and an operating temperature of 0-60 degrees Celsius.
