>>>>>型号:IS200VCRCH1B Mark VI印刷电路板 三重冗余控制
【功能描述】
该IS200VCRCH1B是GE Mark VI板组件。 MKVI 是 Speedtronic 燃气轮机和蒸汽轮机管理系统系列的一部分,自 1960 年代 Mark I 发布以来,通用电气一直在开发和改进该系统。MKVI 是 Speedtronic 系列中的第五个管理系统,具有对所有保护参数和关键控制的三重冗余控制,以及用于保护和监控涡轮系统的先进控制机制。
该IS200VCRCH1B用作分立式输入/输出板。这是一款单插槽板,具有与VCCC板相同的功能,但不包括子板,因此占用的机架空间更少。但是,由于此板的继电器输出使用 VME 机架上的 J3/J4 端口,因此电缆必须放置在前面板上。如果不希望这样做,请使用 VCCC 板而不是 VCRC PCB。
IS200VCRCH1B有一个带有两个电缆连接器(J33 和 J44)的前面板。面板还包含三个 LED 组件,它们位于电路板的顶角附近。这些 LED 为绿色、红色和橙色,并标记为“运行”、“失败”和“状态”。
IS200VCRCH1B Mark VI 印刷电路板具有三重冗余控制功能。
三重冗余控制是一种提高系统可靠性和稳定性的技术,通过在系统中采用三个独立的控制通道,每个通道都执行相同的控制任务,但彼此之间相互独立。这样,即使其中一个通道出现故障或异常情况,其他两个通道仍能继续工作,确保系统的正常运行。
在 IS200VCRCH1B Mark VI 印刷电路板中,三重冗余控制功能可能体现在以下几个方面:
电源冗余:该电路板可能具有三个独立的电源通道,每个通道都为系统提供电源。即使其中一个电源通道出现故障,其他两个通道仍能继续供电,确保系统的稳定运行。
信号冗余:该电路板可能采用三个独立的信号通道来传输控制信号。每个通道都执行相同的控制任务,但彼此之间相互独立。这样,即使其中一个信号通道出现故障或异常情况,其他两个通道仍能继续传输控制信号,确保系统的正常运行。
处理器冗余:该电路板可能具有三个独立的处理器通道,每个通道都执行相同的控制任务。每个处理器都独立运行,但相互之间进行数据同步和校验。这样,即使其中一个处理器出现故障或异常情况,其他两个处理器仍能继续执行控制任务,确保系统的正常运行。
需要注意的是,具体的应用和功能可能会因实际设计和应用需求而有所不同。因此,在使用 IS200VCRCH1B Mark VI 印刷电路板时,建议参考相关的技术文档和数据手册,以了解其详细的功能和应用范围。
>>>>>型号:IS200VCRCH1B Mark VI印刷电路板 三重冗余控制
【英文介绍】
The IS200VCRCH1B is a GE Mark VI board component. The MKVI is part of the Speedtronic family of gas turbine and steam turbine management systems that GE has been developing and improving since the release of the Mark I in the 1960s. The MKVI is the fifth management system in the Speedtronic family, featuring triple redundant control over all protection parameters and critical controls, as well as advanced control mechanisms for protecting and monitoring turbine systems.
The IS200VCRCH1B is used as a separate input/output board. It is a single-slot board that has the same features as the VCCC board, but does not include a subboard, so it takes up less rack space. However, since the relay output of this board uses the J3/J4 port on the VME rack, the cable must be placed on the front panel. If you do not wish to do so, use a VCCC board instead of a VCRC PCB.
The IS200VCRCH1B has a front panel with two cable connectors (J33 and J44). The panel also contains three LED components, which are located near the top corner of the board. These leds are green, red, and orange, and are labeled "Run," "Fail," and "Status."
The IS200VCRCH1B Mark VI printed circuit board features triple redundancy control.
Triple redundancy control is a technique that improves the reliability and stability of a system by employing three independent control channels in the system, each of which performs the same control task but is independent of each other. In this way, even if one of the channels fails or is abnormal, the other two channels can continue to work to ensure the normal operation of the system.
In the IS200VCRCH1B Mark VI printed circuit board, the triple redundancy control function may be reflected in the following aspects:
Power redundancy: The board may have three separate power channels, each providing power to the system. Even if one of the power channels fails, the other two channels continue to supply power to ensure the stable operation of the system.
Signal redundancy: The board may use three separate signal channels to transmit control signals. Each channel performs the same control task, but is independent of each other. In this way, even if one of the signal channels fails or is abnormal, the other two channels can continue to transmit control signals to ensure the normal operation of the system.
Processor redundancy: The board may have three separate processor channels, each performing the same control task. Each processor operates independently, but synchronizes and verifies data with each other. In this way, even if one processor fails or is abnormal, the other two processors can continue to perform control tasks and ensure the normal operation of the system.
It is important to note that specific applications and features may vary depending on actual design and application requirements. Therefore, when using the IS200VCRCH1B Mark VI printed circuit board, it is recommended to refer to the relevant technical documentation and data manual to understand its detailed function and application scope.
