>>>>>型号:3500/22M 数据接口模块 I/O模块继电器
【功能描述】
特征
10.5 瓦功耗
USB-B 前面板
10Base-T 或 100Base-TX 以太网，自动感应
100Base-FX 光纤以太网
机架重置按钮
报警前和报警后数据
LED指示灯
I/O模块继电器
本特利内华达 3500/22M 数据接口模块是 3500 监控系统与兼容系统之间的接口 软件（系统 1* 状态监测和诊断软件以及 3500 系统配置软件）。这 TDI 将 3500/20 机架接口模块 （RIM） 的功能与通信的数据采集功能相结合 TDXnet 等处理器。
TDI 位于 3500 机架电源附近的插槽中。它与 M 系列显示器（3500/40M、 3500/42M等）持续收集稳态和瞬态动态（波形）数据，并将这些数据传递到 与主机软件的以太网链路。有关详细信息，请参阅本文档末尾的“兼容性”部分 信息。
静态数据捕获功能是 TDI 的标准配置。但是，使用可选的通道启用磁盘将允许 TDI 也用于捕获动态和高分辨率瞬态数据。TDI 包含通信处理器 在 3500 机架内运行。
尽管 TDI 提供了整个机架通用的某些功能，但它不是关键监控路径和 对整个监控系统的正常、正常运行没有影响，对机械进行自动保护。每 3500 机架需要一个 TDI 或 RIM，它们始终占用插槽 1（靠近电源）。
>>>>>型号:3500/22M 数据接口模块 I/O模块继电器
【英文介绍】
trait
10.5W power consumption
USB-B front panel
10Base-T or 100Base-TX Ethernet, automatic sensing
100Base-FX Fiber Ethernet
Rack reset button
Pre - and post-alarm data
LED indicator
I/O module relay
The Bentley Nevada 3500/22M Data Interface Module is the interface software between the 3500 monitoring system and compatible systems (System 1* condition monitoring and diagnostic software and 3500 system configuration software). This TDI combines the capabilities of 3500/20 Rack Interface Module (RIM) with the data acquisition capabilities of communication processors such as TDXnet.
The TDI is located in a slot near the power supply in the rack 3500. It continuously collects steady-state and transient dynamic (waveform) data with M-series displays (3500/40M, 3500/42M, etc.) and passes this data to the Ethernet link with the host software. For more information, see the "Compatibility" section at the end of this document.
Static data capture is standard in TDI. However, enabling the disk with an optional channel will allow TDI to also be used to capture dynamic and high-resolution transient data. The TDI contains a communication processor running in 3500 racks.
Although TDI provides certain functions common to the entire rack, it is not a critical monitoring path and has no impact on the normal and normal operation of the entire monitoring system, which automatically protects the machinery. One TDI or RIM is required for every 3500 racks, and they always occupy slot 1 (near the power supply).
