>>>型号:1784-KTX 通信接口卡 用于自动化系统
【功能描述】
1784-KTX是NetLinx系列的一种通信接口卡。该卡是一种半长ISA卡,可以安装在16位的ISA或EISA插槽中,但绝对不能安装在8位扩展槽中。卡上仅有一个通道,并且它还可以作为远程I/O扫描器使用。
1784-KTX卡可以充当DH+或DH-485网络上的一个节点,并直接连接到PLC-2/PLC-3控制器。这种卡在工业自动化系统中扮演着重要的角色,可以实现对设备和系统的精确控制和监控。
1784-KTX卡的工作温度范围为32至140华氏度,储存或运输时的环境温度范围应为-40至185华氏度。同时,卡周围的非冷凝相对湿度应保持在5%到95%之间。该卡的振动等级为10至60赫兹,位移为0.012英寸。
在安装1784-KTX卡之前,必须配置卡的中断设置和基本内存地址。并且,由于它基于CMOS技术,对静电放电(ESD)敏感,因此在处理时需要格外小心。
>>>>型号:1784-KTX 通信接口卡 用于自动化系统
【英文介绍】
The 1784-KTX is a communication interface card of the NetLinx series. The card is a half-length ISA card that can be installed in a 16-bit ISA or EISA slot, but definitely not in an 8-bit expansion slot. There
is only one channel on the card, and it can also be used as a remote I/O scanner.
The 1784-KTX card can act as a node on a DH+ or DH-485 network and connect directly to a PLC-2/PLC-3 controller. This card plays an important role in industrial automation systems, enabling precise control
and monitoring of equipment and systems.
The 1784-KTX card operates in a temperature range of 32 to 140 degrees Fahrenheit, and the ambient temperature range for storage or transportation should be -40 to 185 degrees Fahrenheit. At the same time,
the non-condensing relative humidity around the card should be maintained between 5% and 95%. The card has a vibration rating of 10 to 60 Hz and a displacement of 0.012 inches.
Before installing the 1784-KTX card, the interrupt Settings and basic memory address of the card must be configured. And, because it is based on CMOS technology and is sensitive to electrostatic discharge (ESD),
extra care is needed when handling it.
