>>>型号:1746-OW16 16点继电器输出模块 具备故障诊断功能
【功能描述】
1746-OW16是一款16点继电器输出模块，它是SLC 500系列PLC（可编程逻辑控制器）的一部分。这款模块的主要功能是将PLC内部的逻辑控制信号转换为实际的继电器输出，以驱动现场的负载设备。
1746-OW16的输出点数为16点，每8点共用一个公共端。它的工作电压范围非常广泛，可以是交流5伏至265伏，47赫兹至63赫兹，也可以是直流5伏至125伏。这使得该模块能够适应多种不同的电气环境，从而提高了其应用的灵活性。
在信号延迟方面，当模块处于ON或OFF状态时，其最大信号延迟均为10毫秒。这种快速的响应时间使得该模块能够迅速、准确地响应PLC的控制指令。
1746-OW16模块还具有较高的电气性能。在交流运行时，其持续电流为2.5安培；在直流125V下，持续电流为1.0安培；在24VDC下运行时，持续电流为2.0安培。同时，它的最大散热为5.7瓦，能够有效地保持模块的稳定运行。
1746-OW16模块还具备故障诊断功能。每个输出点都配备有状态指示灯，当逻辑指示灯亮起时，表示处理器已经在逻辑上接通了输出设备；当输出指示灯亮起时，表示已经有实际电流流人输出设备。这种设计使得故障诊断变得更为方便和直观。
总的来说，1746-OW16是一款功能强大、性能稳定的继电器输出模块。它适用于各种工业自动化应用，能够准确、快速地响应PLC的控制指令，并驱动现场的负载设备。同时，其广泛的电压范围和较高的电气性能也使得它在各种电气环境下都能表现出色。
>>>>型号:1746-OW16 16点继电器输出模块 具备故障诊断功能
【英文介绍】
The 1746-OW16 is a 16-point relay output module that is part of the SLC 500 series PLC (Programmable Logic Controller). The main function of this module is to convert the logic control signal inside the PLC into
the actual relay output to drive the load equipment in the field.
1746-OW16 has 16 output points and shares a common terminal every 8 points. It operates in a very wide range of voltages, from AC 5 volts to 265 volts, 47 Hertz to 63 Hertz, and DC 5 volts to 125 volts. This allows
the module to adapt to many different electrical environments, thus increasing the flexibility of its application.
In terms of signal delay, when the module is ON or OFF, its maximum signal delay is 10 milliseconds. This fast response time enables the module to respond quickly and accurately to the PLC's control instructions.
The 1746-OW16 module also has high electrical performance. In AC operation, its continuous current is 2.5 amps; At 125V DC, the continuous current is 1.0 amp; When operating at 24VDC, the continuous current is
2.0 amps. At the same time, it has a maximum heat dissipation of 5.7 watts, which can effectively maintain the stable operation of the module.
The 1746-OW16 module also has a fault diagnosis function. Each output point is equipped with a status indicator. When the logic indicator is on, it indicates that the processor has logically connected the output
device. When the output indicator lights up, it means that there is actual current flowing to the output device. This design makes fault diagnosis more convenient and intuitive.
Overall, the 1746-OW16 is a powerful and stable relay output module. It is suitable for a variety of industrial automation applications, can accurately and quickly respond to PLC control instructions, and drive the
load equipment in the field. At the same time, its wide voltage range and high electrical performance also make it excellent in a variety of electrical environments.
