>>>>>型号:DS200CPCAG1ABB 功率继电器 内部有活动部件
【功能描述】
GE接触器先导板DS200CPCAG1ABB具有一个12针连接器和两个2针连接器。它还具有四个接线端子，最多可连接12根信号线。GE接触器先导板DS200CPCAG1ABB还装有24VDC 15A插座功率继电器。
继电器内部有活动部件，因此在驱动器中安装电路板时需要仔细考虑。如果继电器撞到驱动柜内的金属结构或其他组件，则很容易损坏。而且继电器很高，从板子表面突出，很容易被击中。将主板滑入驱动器机柜时，请确保您能清楚地看到主板和机柜内部。慢慢插入电路板并将其与机架上的螺钉对齐。一只手将螺钉插入孔中，另一只手转动螺丝刀以固定螺钉。但是，不要将电路板固定得太紧，以致螺丝使电路板破裂，从而损坏电路板。如果垫圈在有缺陷的电路板上提供或使用垫圈，请使用垫圈。
>>>>>型号:DS200CPCAG1ABB 功率继电器 内部有活动部件
【英文介绍】
The GE contactor pilot plate DS200CPCAG1ABB has one 12-pin connector and two 2-pin connectors. It also has four terminals and can connect up to 12 signal wires. The GE contactor pilot board DS200CPCAG1ABB is also equipped with a 24VDC 15A socket power relay.
There are moving parts inside the relay, so careful consideration is required when installing the circuit board in the driver. If the relay hits the metal structure or other components in the drive cabinet, it is easily damaged. And the relay is high, protruding from the surface of the board and easy to hit. When sliding the motherboard into the drive cabinet, make sure you have a clear view of the motherboard and the inside of the cabinet. Slowly insert the board and align it with the screws on the rack. Insert the screw into the hole with one hand and turn the screwdriver with the other hand to secure the screw. However, do not secure the board so tightly that the screws break the board and damage it. If the washer is supplied or used on a defective circuit board, use a washer.
>>>>>型号:DS200CPCAG1ABB 功率继电器 内部有活动部件
