>>>>>型号:IS200EPSMG1AED 伺服阀终端板 低电平信号
【功能描述】
IS200EPSMG1AED是几个TSVO伺服阀终端板之一，最初由通用电气公司为其GE Mark VI汽轮机控制系统创建和销售。在大多数Speedtronic应用中，这种伺服终端板通常连接到三线圈伺服致动器。
IS200EPSMG1AED伺服阀板设计为使用低电平信号。这些信号可能包括0至+/-50 V直流模拟信号、交流信号(额定电压低于24 VAC)或4至20 mA电流回路信号。
这块板重约2.00磅。
IS200EPSMG1AED沿两个长边都有缺口。一条长边在拐角处有凹口，而另一条沿其长度方向有较小的等距凹口。这块板是工厂在三个角上钻孔的。安装在电路板表面的元件带有参考标记，也可能有其原始制造商零件号；这些可以引导您查阅数据手册，了解更多信息。
IS200EPSMG1AED由六个d形外壳连接器、两个端子板和几个垂直插头组成。它还有四个变压器、晶体管、继电器、集成电路、电阻器和电容器。最后，电路板有六个跳线开关。每个跳线有六种可能的设置。
特征
为励磁系统提供调节电源
紧凑的模块化设计，便于安装和维护
内置保护功能，实现安全可靠的操作
IS200EPSMG1AED是专为通用电气励磁系统设计的高质量电源模块。它提供稳定而精确的功率，以确保励磁系统的最佳性能和可靠性。
IS200EPSMG1AED是GE EX2100励磁机电源模块。该板负责将EPDM板的125VDC电压转换为EX2100控制系统所需的各种电压。
激励电源型号IS200EPSMG1AED安装在EPBP背板中，为其他控制器提供逻辑电平电源。EPSM型号的电源方面，EPDM发出125 VDC电源，EPSM收到电源后将产生5 VDC、15 VDC或24 VDC电压。M1、M2和C控制器的电源位于控制柜中控制机架下方的电源模块中。
来自EPSM模块的电力也被发送到外部模块。24 VDC电源提供给撬棒模块、EDCF、EGDM和EDEX去励磁模块。ECTB和EXTB模块使用用于触点润湿的隔离70 VDC。由于IS200EPSMG1AED模块是A版本，因此该板不向后兼容。
应用领域
IS200EPSMG1AED GE励磁机电源模块主要应用于发电厂、电力系统的励磁控制领域，如火电厂、水电站等。
>>>>>型号:IS200EPSMG1AED 伺服阀终端板 低电平信号
【英文介绍】
S200EGPAG1BCA GE IS200EGPAG1BCA
IS200EGPAG1BCA Simply said that the driver board is equivalent to a component connecting the host and the display, the host input information through the driver board and then through the driver board connected to the display output.
The more important integrated circuits on the IS200EGPAG1BCA driver board are the main control chip (Sealer chip) and the microcontroller (MCU). The input interface of the IS200EGPAG1BCA driver board is connected to the main control chip of the computer motherboard graphics card through a connection line, and the output interface is connected to the LCD panel through one or two signal transmission lines.
The IS200EGPAG1BCA is a pulse amplifier board specially designed for exciter gates. It amplifies the pulse signal to ensure that the gate in the exciter system works properly.
The GE EX2100 IS200EGPAG1BCA exciter gate pulse amplifier board is used to connect the control to the power bridge in the control system. It is responsible for connecting current conduction feedback, temperature monitoring and bridging airflow.
The gate pulse amplifier board number IS200EGPAG1BCA is located in the power conversion cabinet and can be connected to the power conversion module. This module is one of the boards marked below the bridge and the protection board/module, and although the board can operate independently, it usually requires power from one of the EPDM modules.
The IS200EGPAG1BCA board receives feedback from two thermal switches mounted on the SCR radiator. These switches trigger and disconnect at alarm and trip levels and are directly connected to the IS200EGPAG1BCA. The temperature the switch must reach before triggering is a trip level of 190°F and an alarm level of 170°F. If only one switch is open, an overheating alarm about the bridge has occurred, if both switches are open, it indicates that a trip and a fault has occurred, and the switches can be opened separately or together.
