>>>>>型号:IS200DTAIH1ACC 印刷电路板 涡轮机控制部件
【功能描述】
IS200DTAIH1ACC印刷电路板由GE工业系统公司制造，用于其Mark VI Speedtronic系列自动涡轮机控制和涡轮机控制部件。鉴于该特定PCB作为变压器组件板的预期功能，已通过包含单一功能修订版进行了修改，评级为“A”级。此A级功能修订版被归类为功能修订版，因为它极大地增强了该DBIA缩写板的性能规格和整体功能，并且可能会略微改变产品的尺寸。IS200DTAIH1ACC是DBIA的缩写，因为在许多行业圈子中，它通常被简单地称为DBIA制造商指定的功能同义词。
硬件提示和规格
IS200DTAIH1ACC印刷电路板的基板上贴有许多独特的硬件组件，其功能是变压器组件板。网上似乎相对缺乏制造商发行的IS200DBIA原始说明材料，因此以下大部分信息将由我们熟练的服务技术人员对PCB进行彻底、知识渊博的目视检查来收集。在硬件组件方面，IS200DTAIH1ACC Transformer组件板的面板由一系列电容器和电容器插槽组成，标记为C1至C11。虽然IS200DTAIH1ACC基板上确实存在11个用于放置电容器的插槽，但该DBIA PCB的电路板组件配置中仅包含插槽C2、C3、C6、C7和C9上的电容器。IS200DTAIH1ACC板组件中包含两个小晶体管，标记为Q3和Q5。此Mark VI Speedtronic系列型号的基板上有两个LED指示灯;标记为“ON”和“OFF”，并带有标准命名法DS1和DS2。IS200DTAIH1ACC板的组件中包含一系列二极管，用于电流方向。这些二极管包括两个相当大的电路，位于印刷电路板的右上角;标有警告“RTV完全顶部和底部”。在目视检查IS200DTAIH1ACC PCB时，其他各种工厂印刷的标签是显而易见的，包括：
DBIAG_A
6豪1
IS200DTAIH1ACC部件号
DCP（E5和E6）
TPL和PL
PC和PE标签
NCS4W条形码标签
在这块板的背面;¥1800 94V-0 CTI 4
>>>>>型号:IS200DTAIH1ACC 印刷电路板 涡轮机控制部件
【英文介绍】
The IS200DTAIH1ACC printed circuit board is manufactured by GE Industrial Systems for its Mark VI Speedtronic family of automatic turbine controls and turbine control components. Given the intended function of this particular PCB as A transformer assembly board, it has been modified by including a single function revision, rated "A". This Class A Feature revision is classified as a feature revision because it greatly enhances the performance specifications and overall functionality of this DBIA abbreviated board and may slightly change the size of the product. IS200DTAIH1ACC is an abbreviation for DBIA because in many industry circles it is often referred to simply as a functional synonym for DBIA as specified by the manufacturer.
Hardware tips and specifications
There are many unique hardware components attached to the substrate of the IS200DTAIH1ACC printed circuit board, which functions as a transformer assembly board. There seems to be a relative lack of manufacturer-issued IS200DBIA original instruction material online, so much of the information below will be gleaned by a thorough, knowledgeable visual inspection of the PCB by our skilled service technicians. In terms of hardware components, the panel of the IS200DTAIH1ACC Transformer component board consists of a series of capacitors and capacitor slots, labeled C1 to C11. While 11 slots for capacitors do exist on the IS200DTAIH1ACC substrate, the board assembly configuration for this DBIA PCB only contains capacitors on slots C2, C3, C6, C7, and C9. The IS200DTAIH1ACC board assembly contains two small transistors, labeled Q3 and Q5. This Mark VI Speedtronic series model has two LED indicators on the substrate; Labeled "ON" and "OFF" with standard nomenclature DS1 and DS2. The components of the IS200DTAIH1ACC board contain a series of diodes for current direction. These diodes consist of two fairly large circuits located in the upper right corner of the printed circuit board; Marked with warning "RTV full top and bottom". A variety of other factory-printed labels are evident when visually inspecting the IS200DTAIH1ACC PCB, including:
DBIAG_A
6 Champions 1
IS200DTAIH1ACC Component number
DCP (E5 and E6)
TPL and PL
PC and PE labels
NCS4W barcode label
On the back of this board; ¥1800 94V-0 CTI 4
