>>>>>型号:IS220PPRFH1A 主网关模块 模拟输出包
【功能描述】
产品描述
型号IS220PPRFH1A在通用电气生产的Mark VI系列中被描述为PROFIBUS主网关模块。虽然该型号设计用于Mark VI系列，但它也可用于Mark VIe和Mark VIeS系列。PPRF模型被视为模拟输出包，通常与IS200SPIDG1A附件ID板一起使用。I/O包和端子板一起经过评级和认证，可用于危险和非危险场所。
使用IS220PPRFH1A型号时，必须遵循电气规范，以消除潜在的财产损失或在某些情况下的人身伤害。有两种规格，标有电压和电流。电源电压范围为27.4至28.6 VDC，标称电源电压为28.0 VDC。PPRF电池组使用的电源电流最大为0.18 ADC。PPRF模型还必须使用特定的温度范围;该温度范围为-4至131°F或-20至55°C。
如上所述，IS220PPRFH1A型号被评定用于危险和非危险场所。对于每个位置，都有一个列表认证。无害认证为UL E207685，与I类2区A、B、C、D组和I类2区IIC组认证相同。ATEX Zone 2，Group IIC的认证是UL DEMKO 12 ATEX 1114875X。如需更多认证，请参阅GEH-6725 Mark VIe和Mark VIeS控制设备HazLoc手册。
>>>>>型号:IS220PPRFH1A 主网关模块 模拟输出包
【英文介绍】
Product description
The model IS220PPRFH1A is described in the Mark VI series produced by General Electric as a PROFIBUS main gateway module. While this model is designed for the Mark VI series, it is also available for the Mark VIe and Mark VIeS series. The PPRF model is considered an analog output package and is commonly used with the IS200SPIDG1A Accessory ID board. The I/O packet and the terminal board together are rated and certified for use in hazardous and non-hazardous locations.
Electrical codes must be followed when using IS220PPRFH1A models to eliminate potential property damage or, in some cases, personal injury. There are two sizes, labeled voltage and current. The supply voltage ranges from 27.4 to 28.6 VDC, and the nominal supply voltage is 28.0 VDC. The PPRF battery pack uses a supply current of up to 0.18 ADC. The PPRF model must also use a specific temperature range; This temperature range is -4 to 131°F or -20 to 55°C.
As mentioned above, the IS220PPRFH1A model is rated for use in hazardous and non-hazardous locations. For each location, there is a list authentication. The harmless certification is UL E207685, the same as the Class I 2 Area A, B, C, D and Class I 2 Area IIC Group certification. The certification of ATEX Zone 2, Group IIC is UL DEMKO 12 ATEX 1114875X. For further certification, please refer to the GEH-6725 Mark VIe and Mark VIeS Control Equipment HazLoc Manual.
>>>>>型号:IS220PPRFH1A 主网关模块 模拟输出包
