DS2020PDMAG6 | DS215DMCBG1AZZ03A | 配电模块

　　产品型号： DS2020PDMAG6

　　产品类型：配电模块

　　成色：全新/非全新

　　质保：一年

　　制造国：美国

　　系列：Mark VI

　　可用性：现货

　　DS2020PDMAG6 是通用电气制造的配电模块，是 Mark V 的一部分，用于燃气轮机控制管理系统。配电模块 (PDM) 为 Mark VI 系统提供 125 V 直流和 115 V 交流(或 230 V 交流)的电压，适用于所有机架和终端板。在那些使用远程 I/O 机柜的系统中，控制柜还有第二个版本的 PDM。

　　电源滤波器用于使用客户的 125 V de 和 115/230 V 交流电源进入 PDM。一个或两个输出 125 V DC 的 AC/DC 转换器通过电缆连接到交流电源。为了创建备用电源，然后将该去电压电缆接回连接到主直流电源的 PDM 和二极管。VME机架和终端板接收此电源分配。AC/DC转换器可以处理115 V或230 V AC。对于在 115 V 或 230 V 下运行，变压器电缆必须插入 JTX1 或 JTX2。PDM 用于收集诊断数据，然后将其链接到安装在 DIN 导轨上的端子板。之后，电缆穿过 J301 到达机架“R”中的 VCMI。熔断并电缆连接到继电器端子板的是交流馈电 J17–20。接口 (I/O) 机柜、保护模块、TRPG、TREG 和 TRLY 都具有熔断和接线的 125 V 直流馈线。PDM 通过控制功率滤波器 (CPF) 提供，可降低 EMI 噪声，以确保向电路板提供无噪声电源。如下图所示，CPF 机架可以存储两个或三个 Corcom 30 A 滤波器模块。在熔断并连接到 TBCI 板之前，触点输入端的电源首先通过 TB2、电阻 R3 和 R4 以及 TB2。触点输入采用125 V dc激励电压。

　　WOC 拥有最大的 Speedtronic Mark V 更换备件库存，我们可以在 12 个月的保修期内维修您的故障零件。WORLD OF CONTROLS还可以提供未使用和重建的备份，保修期长达24个月。我们的专家团队全天候为您提供支持。我们WOC的销售团队很乐意协助您满足任何自动化要求。请通过电话或电子邮件与我们的工作人员联系，了解任何零件和维修的价格和可用性。

　　常见问题解答

　　什么是 GE Mark V DS2020PDMAG6?

　　DS2020PDMAG6 是一款配电模块，可为所有机架和终端板的 Mark VI 系统提供 125 V 直流和 115 V 交流电。

　　产品是真正的OEM单位吗?

　　这些物品已通过WOC质量控制认证，是通过OEM或独立第三方渠道获得的正品OEM单位。

　　DS2020PDMAG6 | DS215DMCBG1AZZ03A | Power distribution module

　　Product model: DS2020PDMAG6

　　Product type: Power distribution module

　　Finish: New/not new

　　Warranty: One year

　　Country of Manufacture: USA

　　Series: Mark VI

　　Availability: In stock

　　The DS2020PDMAG6 is a power distribution module manufactured by General Electric as part of the Mark V for gas turbine control management systems. The Power Distribution Module (PDM) provides 125 V DC and 115 V AC (or 230 V AC) voltages to the Mark VI system for all racks and end boards. In those systems that use remote I/O cabinets, the control cabinet also has a second version of PDM.

　　The power filter is used to enter the PDM using the customer's 125 V de and 115/230 V AC power supplies. One or two AC/DC converters with 125 V DC output are connected to the AC power supply via cable. To create a backup power supply, then connect the devoltage cable back to the PDM and diode connected to the main DC power supply. The VME rack and terminal board receive this power distribution. AC/DC converters can handle either 115 V or 230 V AC. For operation at 115 V or 230 V, the transformer cable must be plugged into JTX1 or JTX2. The PDM is used to collect diagnostic data, which is then linked to the terminal plate mounted on the DIN rail. After that, the cable passes through J301 to the VCMI in rack "R". The fuse and cable connected to the relay terminal board is AC feed J17-20. Interface (I/O) Cabinets, protection modules, TRPG, TREG, and TRLY all have fused and wired 125 V DC feeders. PDM is provided via a control power filter (CPF) that reduces EMI noise to ensure a noise-free power supply to the board. As shown in the figure below, the CPF rack can store two or three Corcom 30 A filter modules. Before fusing and connecting to the TBCI board, the power supply at the contact input first passes through TB2, resistors R3 and R4, and TB2. The contact input uses 125 V dc excitation voltage.

　　WOC has the largest stock of replacement parts for Speedtronic Mark V and we can repair your broken parts under a 12-month warranty. WORLD OF CONTROLS can also provide unused and rebuilt backups with a warranty of up to 24 months. Our team of experts support you around the clock. Our WOC sales team will be happy to assist you with any automation requirements. Please contact our staff by phone or email for pricing and availability of any parts and repairs.

　　Frequently Asked Questions

　　What is GE Mark V DS2020PDMAG6?

　　The DS2020PDMAG6 is a power distribution module that provides 125 V DC and 115 V AC power to Mark VI systems in all racks and terminal boards.

　　Is the product a true OEM unit?

　　These items have been WOC quality control certified and are genuine OEM units obtained through OEM or independent third party channels.
