369-HI-0-M-0-0-0  |   电机管理继电器  |  HYDRAN H201Ti  |  350-0001007807-414001D

       369-HI-0-M-0-0-0  |   电机管理继电器  |  HYDRAN H201Ti  |  350-0001007807-414001D

　　品牌:GE

　　型号:369-HI-0-M-0-0-0

　　品名：电机管理继电器

　　最低订单数量:1项

　　包装零件:新工厂和单独包装的原材料

　　发货时间:3-5天

　　付款:银行转账，西联汇款

　　数字/开关输入 6 光隔离

　　最大环境湿度 高达 95% 的无冷凝

　　控制电源 额定值：20 VA;最大值：65 VA

　　尺寸 约 ： 11.5 英寸(高)x 5.5 英寸(宽)x 8.5 英寸(长)

　　保险丝 3.15 安 H 250 V

　　最大海拔 2000 m (最大)

　　相电流输入 1 A 和 5 A 次级

　　关于 369-HI-0-M-0-0-E 的常见问题

　　369-LO-0-M-F-E-0-E电机管理继电器的控制功率规格是什么?

　　369-LO-0-M-F-E-0-E 具有低 (LO) 控制功率规格。VDC 范围为 20-60，此 369 Multilin 电机管理继电器的 VAC 控制功率范围为 20 至 48。与高 (HI) 选项(50-300 VDC 和 60 至 265 VAC 控制功率)相比，这种低规格是比较的。

　　369-LO-0-M-F-E-0-E Multilin 通用电气数字继电器有哪些附加功能?

　　369-LO-0-M-F-E-0-E 的附加功能是可选的计量套件。除了基本单元的单个模拟输出外，该套件还提供三个额外的可配置模拟输出。该套件还为设备提供电源和电压元件的输入，能够测量各种细节，例如 V、kW 等。

　　369-LO-0-M-F-E-0-E 还包含由 (F) 选项表示的可选光纤端口。光纤的此数据链路适用于更恶劣的环境或 RRTD 连接。光纤尺寸为 50/125、62.5/125、100/140 和 200 微米。LED 发射器的类型是具有多模功能的 820 nm LED。

　　369-LO-0-M-F-E-0-E 的可选光纤端口的用途是什么?

　　369-LO-0-M-F-E-0-E 的光纤端口(选项 F)的目的是允许远程模块 RTD 连接到电机管理继电器。

　　Brand :GE

　　Model :369-HI-0-M-0-0-0

　　Product name: Motor management relay

　　Minimum order quantity :1 item

　　Packaging parts: raw materials for new plant and separate packaging

　　Delivery time :3-5 days

　　Payment: Bank transfer, Western Union

　　Digital/switch input 6 Optical isolation

　　Non-condensing with maximum ambient humidity up to 95%

　　Control power rating: 20 VA; Maximum value: 65 VA

　　Dimensions: 11.5 inches (H) x 5.5 inches (W) x 8.5 inches (L)

　　Fuse 3.15 amp H 250 V

　　Maximum altitude 2000 m (Max)

　　Phase current input 1 A and 5 A secondary

　　Frequently Asked Questions about 369-HI-0-M-0-0-E

　　What is the control power specification of the 369-LO-0-M-F-E-0-E motor management relay?

　　The 369-LO-0-M-F-E-0-E has a low (LO) control power specification. With a VDC range of 20-60, this 369 Multilin motor management relay has a VAC control power range of 20 to 48. This low specification is comparable to the high (HI) options (50-300 VDC and 60 to 265 VAC control power).

　　369-LO-0-M-F-E-0-E Multilin What additional features do GE digital relays have?

　　Additional features of the 369-LO-0-M-F-E-0-E are optional metering kits. In addition to the single analog output of the base unit, the kit offers three additional configurable analog outputs. The kit also provides input to the power and voltage components of the device, capable of measuring various details such as V, kW, etc.

　　369-LO-0-M-F-E-0-E also contains an optional fiber port indicated by the (F) option. Fiber optic for this data link is suitable for harsher environments or RRTD connections. Fiber sizes are 50/125, 62.5/125, 100/140, and 200 microns. The type of LED transmitter is an 820 nm LED with multi-mode capabilities.

　　What is the purpose of the optional fiber port for 369-LO-0-M-F-E-0-E?

　　The optical fiber port (option F) of the 369-LO-0-M-F-E-0-E is designed to allow the remote module RTD to connect to the motor management relay.+
