IS200JPDHG1AAA  |  I/O   |  有助于可靠有效地处理电压监测

　　模型:IS200JPDHG1AAA

　　型号| 类型高密度配电

　　安装 | DIN导轨捕捉器

　　额定电值24/28 VDC

　　6 pin插头连接器数量2

　　温度范围-30至65°C

　　功率测量单元直流电压

　　产品描述

　　IS200JPDHG1AAA型号作为高密度配电卡销售，通常用于Mark VI系列。当设备运行时，它可以发送28伏的直流电到多达三个以太网交换机以及24个Mark VIe I/O组。如果需要，您可以购买更多的JPDH包，然后将它们连接在一起，为I/O包提供更大的功率。请注意，当连接更多的JPDH卡在一起时，它们必须以菊花链的方式连接。

　　主板的物理部件是29个母脚插头连接器。其中29个为6针连接器，其余27个为2针连接器;24个连接器分为三排，每排8个连接器。这些行中的连接器被标记为JT1到JT8、JR1到JR8和JS1到JS8。这些线路是为单个I/O数据包提供主要电源的馈源。I/O分组电路将包括一个温度系数熔断器装置，它将用于保护分支电路并提供一个正温度熔断器。

　　IS200JPDHG1AAA板可用于许多危险场所。该板可用于ATEX 2区IIC组，I类2区A至D组和I类2区IIC组。该板也可以在非危险场所使用，ULE207685认证代码适用于非危险场所使用。

　　安装

　　接线配置:IS200JPDHG1AAA电压检测和断路器继电器接线:将电压检测电路和必要的断路器继电器连接小心地连接到指定的I/O端子TB1上。这种设置有助于可靠有效地处理电压监测和系统跳闸激活。

　　被动脉冲速率拾取器:被动脉冲速率拾取器连接到TB2，在感应齿轮和精确测量涡轮转速方面发挥关键作用。

　　端子及规格:I/O端子:每个端子(TB1和TB2)均用2颗螺钉固定，保证接线稳定。这些模块设计有24个端子，能够接受高达#12 AWG的电线，实现坚固高效的电线连接。

　　屏蔽端排:IS200JPDHG1AAA屏蔽端排与每个端子相邻，并牢固地连接到机箱接地，提供额外的保护层，防止潜在干扰，确保信号完整性和系统可靠性。

　　这种精心的布线配置，将特定组件连接到指定的端子，以及屏蔽的端带，确保了配线板的安全有序安装。这种谨慎的安装程序对于涡轮系统内的最佳功能和性能至关重要。

　　Model: IS200JPDHG1AAA

　　Model Type High-density power distribution

　　Install DIN rail catchers

　　Rated electrical value 24/28 VDC

　　6 pin plug Number of connectors 2

　　Temperature range -30 to 65 °C

　　Power Measurement unit DC voltage

　　Product description

　　The IS200JPDHG1AAA model is marketed as a high density power distribution card and is commonly used in the Mark VI series. When the unit is operating, it can send 28 volts of direct current to up to three Ethernet switches as well as 24 Mark VIe I/O groups. If needed, you can buy more JPDH packages and then connect them together to provide more power to the I/O packages. Note that when connecting more JPDH cards together, they must be connected in a Daisy chain arrangement.

　　The physical components of the board are 29 female pin plug connectors. 29 of them are 6-pin connectors, and the remaining 27 connectors are 2-pin connectors; The 24 connectors are divided into three rows of eight connectors each. The connectors in these rows are labeled JT1 to JT8, JR1 to JR8, and JS1 to JS8. These lines are the feeds that provide the main power to individual I/O packets. The I/O packet circuit will include a temperature coefficient fuse device, which will be used to protect the branch circuit and provide a positive temperature fuse.

　　The IS200JPDHG1AAA board can be used in many hazardous places. The main locations where this board can be used are ATEX Zone 2 IIC Group, Class I Zone 2 A to D Group, and Class I Zone 2 IIC Group. The board can also be used in non-hazardous places, ULE207685 certification code for use in non-hazardous places.

　　Install

　　Wiring Configuration: IS200JPDHG1AAA Voltage Detection and Circuit Breaker Relay wiring: The voltage detection circuit and the necessary circuit breaker relay connections are carefully connected to the I/O terminal designated TB1. This setting helps to reliably and efficiently handle voltage monitoring and system trip activation.

　　Passive pulse rate pickers: The passive pulse rate pickers are connected to the TB2 and play a key role in sensing the toothed wheels and accurately measuring turbine speed.

　　Terminals and specifications: I/O terminals: Each terminal (TB1 and TB2) is securely secured using two screws to ensure stability and a stable connection. These modules are designed with 24 terminals and are capable of accepting wires up to #12 AWG for robust and efficient wire connections.

　　Shielded end bar: The IS200JPDHG1AAA shielded end bar is adjacent to each terminal and firmly connected to the chassis ground, providing an additional layer of protection against potential interference and ensuring signal integrity and system reliability.

　　This careful wiring configuration, the connection of specific components to specified terminals, and the shielded end strips ensure the safe and orderly installation of the patch boards. This careful installation procedure is essential for optimal function and performance within the turbine system.
