IS220UCSAH1A  |控制器模块  |  用于连接通信

　零件编号 IS220UCSAH1A

　　功能首字母缩略词 UCSA

　　功能描述 PAMC 声学监测器(处理器)

　　说明书 GEH-6725R型

　　PCB涂层 三防漆

　　应用 Mark VIe、Mark VIes、EX2100e、LS2100e

　　功能修订版 1 一个

　　产品类型 Mark VIe 控制器

　　该IS220UCSAH1A是通用电气为Mark VI系统创建的处理器/控制器。Mark VI平台设计用于管理燃气轮机或蒸汽轮机，由GE作为Speedtronic系列的一部分发布。它具有 HMI(人机界面)和专为运行重型涡轮机而设计的软件，例如 CIMPLICITY 图形界面。

　　IS220UCSAH1A 被构建为一个单一的盒装组件，带有一个前面板，用于连接通信，后边缘有两个螺钉支架，三个侧面有格栅开口，允许空气流动。该控制器设计用于在机柜内安装底座。最多可将三个组件彼此相邻安装，以实现紧凑的布置，可轻松为三重冗余系统提供服务。

　　该IS220UCSAH1A适用于 QNX 操作系统。它有一个飞思卡尔8349,667 MHz处理器。该板使用额定电压为 18-36 V 直流、12 瓦的电源。该板可在 0 至 65 摄氏度的温度下使用，即使在最高额定温度下也不需要风扇进行冷却。该板可用于 NFPA 1 类 2 类应用。

　　Part number IS220UCSAH1A

　　Functional acronym UCSA

　　Function Description PAMC Acoustic Monitor (Processor)

　　Instruction Manual GEH-6725R

　　PCB coating three anti-paint

　　Apply Mark VIe, Mark VIes, EX2100e, and LS2100e

　　Feature revision 1 One

　　Product Type Mark VIe Controller

　　The IS220UCSAH1A is a processor/controller created by General Electric for the Mark VI system. The Mark VI platform is designed to manage gas or steam turbines and is released by GE as part of the Speedtronic family. It has an HMI (Human machine interface) and software designed for running heavy duty turbines, such as the CIMPLICITY graphical interface.

　　The IS220UCSAH1A is built as a single boxed assembly with a front panel for connecting communications, two screw brackets on the back edge, and grille openings on three sides to allow air flow. The controller is designed for mounting a base in a cabinet. Up to three components can be installed next to each other for a compact arrangement that easily serves triple-redundant systems.

　　The IS220UCSAH1A is suitable for the QNX operating system. It has a Freescale 8349,667 MHz processor. The board uses a rated voltage of 18-36 V DC, 12 watts of power supply. The board can be used at temperatures from 0 to 65 degrees Celsius and does not require a fan for cooling even at the highest rated temperature. The board can be used for NFPA Class 1 Class 2 applications.
