IS220PAICH2A  |   模拟 I/O 包  |   TMR系统有一个单独的控制模

型号 ：IS220PAICH1A

输入电压范围:12-48VDC

输出电压范围:5VDC。

输出电流:最大10A。

效率:大于90%。

尺寸:170mm x105mmx32mm.

重量:约120g。

运行温度:-20°C至+50°C。

存储温度:-40°C至+70°C。

环境湿度:5%至95%相对湿度(无凝露)

产品描述

该型号被描述为模拟 I/O 包，IS220PAICH1A 型号已被批准用于危险和非危险场所。在模型的正面，有四个指示器。底部还有一个端口，被描述为 I/O 端口。PAIC电池组可以使用多种电压，PAIC电池组的最小电压为27点4伏直流电。

由于 IS220PAICH1A 包能够在许多地点使用，因此有多种与 包相关的认证，其中一些是危险场所、一类二区 IIC 组、一类二区 A、B、C、D 和 ATEX 二区、IIC 组和非危险场所。以下认证用于地点、UL E207685 和 UL DEMKO 12 ATEX 1114875X，请注意 UL E207685 认证在许多地点使用。

有三种型号可以与IS220PAICH1A单元一起使用，分别是IS200STAIH1A和IS200STAIH2A以及IS20TBAIH1C型号。所有这些型号都被称为输入输出端子板。

PAIC I/O 包的典型位置将位于两个可用的 VME 机架之一中，即 13 个或 21 个插槽机架。 请注意，该装置通常与三重模块化冗余架构系统一起使用

。TMR系统有一个单独的控制模块、I/O网络和主处理器卡。

Model: IS220PAICH1A

Input voltage range :12-48VDC

Output voltage range :5VDC.

Output current: Max. 10A.

Efficiency: greater than 90%.

Size :170mm x105mmx32mm.

Weight: About 120g.

Operating temperature :-20°C to +50°C.

Storage temperature :-40°C to +70°C.

Ambient humidity :5% to 95% relative humidity (no condensation)

Product description

The model is described as an analog I/O package, and the IS220PAICH1A model has been approved for use in hazardous and non-hazardous locations. On the front of the model, there are four indicators. There is also a port on the bottom, which is described as an I/O port. The PAIC battery pack can use a variety of voltages, the minimum voltage of the PAIC battery pack is 27.4 volts DC.

Because the IS220PAICH1A package can be used in many locations, there are several certifications related to the package, some of which are hazardous Sites, Zone I II IIC Group, Zone I II A, B, C, D and ATEX Zone II, IIC Group and non-hazardous sites. The following certifications are for locations, UL E207685, and UL DEMKO 12 ATEX 1114875X, please note that the UL E207685 certification is used in many locations.

There are three models that can be used with the IS220PAICH1A unit, the IS200STAIH1A and IS200STAIH2A, and the IS20TBAIH1C model. All of these models are referred to as input/output terminals.

The typical location for a PAIC I/O package will be in one of the two available VME racks, i.e. 13 or 21 slot racks. Note that this device is often used with triple modular redundant architecture systems. The TMR system has a separate control module, I/O network, and main processor card.
