>>>>>型号:DS200DCFBG1BGB 电源板 具有许多电路
【功能描述】
DS200DCFBG1B是通用电气为Mark V板系列制造的电源板。AC2000、CB2000、DC2000 、FC2000、ME2000 和 EX2000 系列机器可以将主板安装在驱动器中。安装后，此卡可以为驱动器提供控制级电源和机箱风扇电源。额定电压在 38 至 115 VAC 之间可通过控制电源变压器直接提供给电路板。该板的频率取决于输入电压，但范围为 0 至 500 kHz。
该主板具有许多电路，可为主板和已安装的驱动器供电。DS200DCFBG1B由电机现场电源、驱动器、AC/DC 监控和控制级电源电路组成。板上的 12 个跳线和 7 个 DIP 开关为用户提供了可配置的系统选项。保险丝开关诊断使用电路板上的两个 LED 和一个霓虹灯指示灯显示。三个保护保险丝可防止电源中断。可以使用电路板上集成的五个测试点来监控电压。
应遵循制造商提供的DS200DCFBG1B和已安装驱动器的安装和存储参数。 这将防止对两个单元造成任何意外或可预防的损坏。有关接线和安装板的完整指南，请参阅设备的手册和数据表。最初，该板和 Mark V 系列的技术支持由制造商通用电气提供。
>>>>>型号:DS200DCFBG1BGB 电源板 具有许多电路
【英文介绍】
The DS200DCFBG1B is a power supply board manufactured by General Electric for the Mark V board series. AC2000, CB2000, DC2000, FC2000, ME2000 and EX2000 series machines can have the motherboard installed in the drive. When installed, the card provides control level power to the driver and chassis fan power. Rated voltages between 38 and 115 VAC can be supplied directly to the board via a control power transformer. The frequency of the board depends on the input voltage, but ranges from 0 to 500 kHz.
The motherboard has a number of circuits that power both the motherboard and the installed drivers. The DS200DCFBG1B consists of a motor field power supply, driver, AC/DC monitoring and control level power supply circuit. The 12 jumpers and 7 DIP switches on the board provide users with configurable system options. Fuse switch diagnostics are displayed using two leds and a neon indicator light on the circuit board. Three protective fuses prevent power outages. The voltage can be monitored using five test points integrated on the board.
Installation and storage parameters for DS200DCFBG1B and installed drives provided by the manufacturer should be followed. This will prevent any accidental or preventable damage to both units. For complete guidance on wiring and mounting boards, refer to the device's manual and data sheet. Initially, technical support for the board and the Mark V series was provided by manufacturer General Electric.
