FBM201  | 模拟输入模块 |   每个通道内部和/或外部电源的发射组件

型号：FBM201

特性

紧凑的设计

Compact FBM201模拟输入接口模块包含8个模拟输入通道，每个通道接受2线，0至20 mA直流输入模拟传感器。 它是Compact 200系列l/0子系统的一部分，详见Compact 200

系列/ 0子系统概述(PSS 41H-2C0V)这些模块执行连接电气输入所需的信号转换信号从现场传感器到FCP。

FBM201与标准HART信号在电气上兼容8通道输入模拟0至20毫安直流传感器信号每个模拟输入通道与其他通道电流隔离地面紧凑，坚固的设计适用于G3(恶劣)环境的外壳

提供转换时间的模拟输入应用程序的执行以及集成时间和变化率限制的可配置选项通过每个通道的sigma-delta数据转换，实现高精度终端组件(ta)用于本地或远程将现场布线连接CompactFBM201模块

每个通道内部和/或外部电源的发射组件

发射器

紧凑型FBM201的设计很窄!

比标准的200系列现场总线

模块(fbm)。它有一个坚固的丙烯腈丁二烯苯乙烯(ABS)外部

电路的物理保护。 专门设计用于安装的外壳

bm提供各种级别的环境保护，直至恶劣的环境

每lSA标准S71.04。

Model: FBM201

peculiarity

Compact design

The Compact FBM201 analog Input interface module contains eight analog input channels, each receiving 2 lines of 0 to 20 mA DC input analog sensors. It is part of the Compact 200 series l/0 subsystem, as described in the Compact 200

Overview of the Series / 0 Subsystem (PSS 41H-2C0V) These modules perform the signal conversion required to connect the electrical input signals from the field sensor to the FCP.

The FBM201 is electrically compatible with standard HART signals 8-channel input analog 0 to 20 mA DC sensor signals Each analog input channel is current isolated from other channels Ground compact, rugged design for enclosures in G3(harsh) environments

Provides conversion time for analog input application execution as well as configurable options for integrating time and rate of change limits through sigma-delta data conversion on each channel, enabling high-precision terminal components (ta) for local or remote connection of field wiring to CompactFBM201 modules

Emission components for internal and/or external power sources in each channel

emitter

The compact FBM201 has a narrow design!

More than the standard 200 series fieldbus

Module (fbm). It has a strong acrylonitrile butadiene styrene (ABS) exterior

Physical protection of the circuit. Housing specifically designed for mounting

bm provides all levels of environmental protection, up to harsh environments

The standard for each lSA is S71.04.
