REF615E 1G HBFGDAAHNDCCBNA11G  |  馈线保护测控装置 REF615

　　型号：REF615E 1G HBFGDAAHNDCCBNA11G

　　类别：馈线保护测控装置 REF615

　　质保：365天

　　货期：3-5天/周

　　发货方式：顺丰/联邦

　　产品净重:4 kg

　　REF615E 1G HBFGDAAHNDCCBNA11G是一款专用于馈线保护测控的装置，可用于公用变电站和工业配电系统的保护，控制，测量和监视，包括具备或不具备分布式电源的辐射型、环形和网格型配电网。REF615是ABB Relion®产品家族中615保护测控装置产品系列的成员。615系列装置具有结构紧凑和易拆卸的特点。615系列保护测控装置是基于IEC 61850标准全新研发和设计的，支持变电站内自动化设备之间互操作与水平通信。该装置可作为配网架空线和馈线的主保护。也可在要求独立或要求冗余的保护系统中的用作后备保护。

　　该系列产品提供多种标准配置，可用于保护中性点不接地，电阻接地，补偿性接地和直接接地网络中的架空线和馈线。仅需根据特定应用进行设置，便可直接投入使用。

　　615系列装置支持多种通信协议，包括IEC 61850版本2，基于IEC 61850-9-2 LE的过程总线，IEC 60870-5-103，Modbus。通过SPA-ZC 302协议转换器，可支持Profibus DVP1 通信。

　　REF615E 1G HBFGDAAHNDCCBNA11G有五个可选标准配置。标准信号配置可以通过保护和测控装置管理工具PCM600的信号矩阵或图形化配置功能进行修改。此外，PCM600中的应用配置功能支持创建多层逻辑，可以使用包括定时器和触发器在内的多种不同逻辑元件。

　　将保护功能与逻辑功能模块相结合，配置可满足用户不同的应用需求。

　　Model: REF615E 1G HBFGDAAHNDCCBNA11G

　　Category: Feeder protection measurement and control device REF615

　　Warranty: 365 days

　　Delivery time: 3-5 days/week

　　Delivery method: SF Express/Federal

　　Net weight: 4kg

　　The REF615E 1G HBFGDAAHNDCCBNA11G is a feeder protection measurement and control device designed for the protection, control, measurement and monitoring of utility substations and industrial distribution systems, including radiant, ring and grid distribution networks with or without distributed power sources. The REF615 is a member of the 615 Protection Measurement and Control Unit family in the ABB Relion® product family. The 615 series devices are compact and easy to disassemble. The 615 series protection and control devices are newly developed and designed based on the IEC 61850 standard to support interoperability and horizontal communication between the automation equipment in the substation. The device can be used as the main protection of overhead lines and feeder lines in distribution network. It can also be used as backup protection in protection systems that require independence or redundancy.

　　Available in a variety of standard configurations, this family can be used to protect neutral ungrounded, resistive grounded, compensatory grounded and direct grounded overhead lines and feeders in networks. Just set it up for your specific application and it's ready to go.

　　The 615 series devices support multiple communication protocols, including IEC 61850 Version 2, the process bus based on IEC 61850-9-2 LE, IEC 60870-5-103, Modbus. Through the SPA-ZC 302 protocol converter, Profibus DVP1 communication can be supported.

　　The REF615E 1G HBFGDAAHNDCCBNA11G comes in five optional standard configurations. The standard signal configuration can be modified through the signal matrix or graphical configuration function of the PCM600 protection and measurement and control device management tool. In addition, the application configuration feature in the PCM600 enables the creation of multiple layers of logic that can use many different logic elements, including timers and triggers.

　　The protection function is combined with the logical function module to meet different application requirements.
