KUC755AE106 励磁控制系统 进行调理和控制

>>>>>型号:KUC755AE106 励磁控制系统 进行调理和控制 【功能描述】 一、定义及作用励磁控制系统是发电过程中不可或缺的重要环节之一,主要用于对发电机产生的电能进行调理和控制。该系统主要包括励磁功率单元和励磁调节器两个部分,发挥着确保发电机稳定工作、提高振荡、降低过调整的作用。二、组件组成励磁功率单元提供直流电流至发电机,以实现对励磁电流的控制;而励磁调节

电话/Phone:18859254943 (微信同号)

邮箱/Email:sales@ygdcs.com

QQ:3561040004

产品详情

>>>>>型号:KUC755AE106 励磁控制系统 进行调理和控制





【功能描述】



一、定义及作用

励磁控制系统是发电过程中不可或缺的重要环节之一,主要用于对发电机产生的电能进行调理和控制。该系统主要包括励磁功率单元和励磁调节器两个部分,发挥着确保发电机稳定工作、提高振荡、降低过调整的作用。

二、组件组成

励磁功率单元提供直流电流至发电机,以实现对励磁电流的控制;而励磁调节器则根据输入参数和预设规则来调控励磁功率单元的输出。整体而言,励磁系统成为了由励磁调节器、励磁功率单元和发电机所构成的闭环控制系统,能够在保证发电机高效工作的同时,提高系统稳定性和可靠性。

三、原理说明

1. KUC755AE106测量比较模块。此单元吸收发电机电压信息,然后将其转换为直流信号,再依据预设直流参考电压进行比较计算,输出相应的电压偏差信号;为了使并列运行的机组能公平公正地分担无功功率,我们还需要加入稳压调节单元。

2. KUC755AE106综合放大模块。这个提升环节主要负责将基础参数测量输出、反馈制约以及辅助限制生成等多元直流信号进行整合放大,最终推送给比例积分环节。该环节可以依据预设的调节规律进行加工处理后输出。适应器环节用于放大信号电压,最终转化为移相控制信号电压以精确调节励磁电压。

四、结论

总之,励磁控制系统对于电力生产具有极为关键的意义。通过理解系统功能、结构组成及其运作原理,我们可以在此基础上制定更为科学有效的运行策略,从而确保发电机组的高效稳定运行。


 >>>>>型号:KUC755AE106 励磁控制系统 进行调理和控制



英文介绍

Abstract: This article mainly discusses the main points of excitation system design and control technology analysis of synchronous generator. The excitation system is very important for the stable and reliable operation of the generator, and also has a positive significance for improving the technical and economic benefits of the power system. In this paper, the excitation control system of 0.5MW European standard small permanent magnet synchronous generator (KUC755AE105) will be discussed in detail.

Key words: synchronous generator; Excitation system; Control technology; Design essentials

Introduction: Excitation system plays a very critical role in the steady state or transient state of synchronous generator, which directly determines the performance characteristics of the generator. An excellent excitation system can not only ensure the quality of the power supply, but also promote the safety and stability of the unit, which ultimately leads to the improvement of the technical and economic benefits of the entire power system. However, if the importance of the excitation control system is ignored in the power system stability calculation, the results can not reach the expected results.

Text: Before the synchronous generator is connected to the grid, its voltage needs to be maintained at a preset value, which means that the excitation regulation system under no-load conditions needs to maintain smooth operation. Once connected to the grid, the unit will operate in parallel with other generators in the power system. At this time, the excitation adjustment system must have the ability to have a positive impact on the stable operation of the power system. Specifically, control accuracy and dynamic performance are common requirements in daily operation.

In addition, the power system design specification also has corresponding provisions for excitation control systems, including stability indicators (such as amplitude margin m≥30db and phase margin y≥50℃), dynamic indicators (overkill Mp≤ 15%-30% and adjustment time tp≤10s) and steady state error e(oo)<1%-2% and other objectives. Based on this, we need to analyze and design the excitation control system from the three dimensions of stability, dynamics and steady-state.

The basic structure of the excitation control system is usually composed of two basic components, namely the excitation power module and the excitation regulator. Among them, the excitation power module is mainly responsible for applying direct current excitation to the synchronous generator rotor, and the excitation regulator realizes the output adjustment by accurately controlling the excitation power module according to the predetermined regulation principle. The whole system is a closed-loop control system which includes excitation regulator, excitation power module and generator set.

Conclusion: In summary, this paper focuses on the design of synchronous generator excitation system and the analysis of control technology. Learn about Binzhou can Operation and maintenance company ZYS450-H and ZYS800-H permanent magnetic synchronous motor is1250-22-10 ild011-4619is1250-35-4820 synchronous motor forth 350,000 kW generator is450-6220 synchronous motor used in power generation industry The output and environmental conditions of the is450-7629 synchronous motor help us to improve the design of the generator, increase its operating efficiency and reduce energy consumption.
