>>>>型号:5SHX2645L0002/3HB012961R0001 闸管开关模块
【功能描述】
5SHX2645L0002/3HB012961R0001是一款晶闸管开关模块
其详细参数和功能如下：
适用电网：适用于415/440V、50Hz的低压电网。
组件选择：使用50kVAr的单个或多个组件，包括25kVAr和10kVAr的选项。
电容器单元兼容性：适用于带或不带失谐电抗器的电容器单元。
切换特性：在零差分电压下实现高速切换。
冷却方式：具有带强制冷却选项的自冷机组。
监测功能：能够监测电源电压、输入触发器和热故障。
电源需求：TSM不需要外部电源，但可选的冷却风扇需要230VAC、50Hz的外部电源运行。
报警扩展：使用30VDC、1A或30VDC无电势触点的可选报警扩展单元。
连接方式：通过带安全盖的铜母线进行牢固连接，并采用尺寸合适的铜质柔性电缆。
触发方式：来自功率因数控制器或其他的12 VDC-24 VDC触发信号装置应连接在“T+和T-”点，用于触发模块开启。同时，可以触发多个晶闸管开关模块，以实现更大的kvar步进容量。
此外，该模块还具备啮齿动物进入保护、符合极端气候条件、符合ROHS、无涡流电缆加热等特性。并且，其IP防护等级为IP20，维护需求较少，具有最低的TCO。
该模块直接安装在低压配电板/面板上，并需要150mm的通风间隙。
>>>>>型号:5SHX2645L0002/3HB012961R0001 闸管开关模块
【英文介绍】
5 shx2645l0002/3 hb012961r0001 is a thyristor switch module
Its detailed parameters and functions are as follows:
Applicable power grid: Suitable for 415/440V, 50Hz low-voltage power grid.
Component selection: Use single or multiple components of 50kVAr, including options for 25kVAr and 10kVAr.
Capacitor unit compatibility: Suitable for capacitor units with or without a detuned reactor.
Switching characteristics: High-speed switching under zero differential voltage.
Cooling method: self-cooling unit with forced cooling option.
Monitoring function: Ability to monitor power supply voltages, input triggers and thermal failures.
Power requirements: The TSM does not require an external power supply, but the optional cooling fan requires an external power supply of 230VAC, 50Hz to operate.
Alarm expansion: Optional alarm expansion units with 30VDC, 1A or 30VDC non-potential contacts.
Connection method: The copper bus with safety cover is firmly connected, and the appropriate size of the copper flexible cable is used.
Trigger mode: The 12 VC-24 VDC trigger signal device from the power factor controller or other should be connected to the "T+ and T-" points to trigger the module to
open. At the same time, multiple thyristor switching modules can be triggered to achieve greater kvar stepping capacity.
In addition, the module offers rodent entry protection, extreme weather conditions, ROHS compliance, vortex free cable heating and other features. Moreover, its IP
protection level is IP20, with less maintenance requirements and the lowest TCO. The module is mounted directly on the low-voltage switchboard/panel and requires a 150mm ventilation gap.
