>>>>>型号:MVI56E-MNETC 以太网端口的配置和管理 网络搭线建桥
【功能描述】
当你需要Modbus®TCP/IP通信，MVI56E-MNETC/MNETCXT模块绝对是你的最佳选择。Modbus TCP/IP增强通信模块支持罗克韦尔自动化ControlLogix可编程自动化控制器（PAC）轻松连接Modicon可编程自动化控制器（PAC），以及多个Modbus TCP/IP服务器兼容的仪器和设备。多客户端模块在支持Modbus TCP/IP网络上的多个服务器时，支持最多30个客户端，从而提高了性能。它还支持多达20个服务器连接，提供与其他DCS和SCADA系统通信的能力。客户端和服务器功能都可以同时运行，模块还可以作为强大的数据集中器运行。
MVI56E-MNETC和MVI56E-MNETCXT功能相同。MVI56E-MNETCXT用于标准过程应用。MVI56E-MNETCXT是专为XT™Logix控制平台设计的，支持它在极端环境下运行。该模块可以在较高的工作温度下运行，并具有保护涂层使它免受恶劣或苛性条件。
MVI56E增强功能包括通过模块的以太网端口的配置和管理，CIPconnect®技术则为ControlNet和EtherNet/IP™网络搭线建桥。
特性优势
支持多达30个客户端和20个服务器
对多服务器应用程序的响应速度更快
当一台服务器设备离线时，最大限度地减少对其他服务器通信的影响
服务器功能提供HMIs访问系统，SCADA和DCS系统
RSLogix™5000集成
模块与RSLogix 5000使用提供的附加的集成指令（AOI）或梯形文件通信
不需要额外的PAC/PLC编程
从梯形逻辑轻松启用/禁用命令
以编程方式启用各种网络设备及其功能以支持多个网络设备应用程序或配方，而无需重新配置模块
远程配置和诊断问题
易于使用的基于Windows的配置软件通过远程机架连接以太网/IP，没有RSLinx要求,控制通过1756的或1756-CNB接口的模块，节省成本。
允许IT支持和自动化网络分割
MVI56向后兼容
通过采用更新的技术，帮助扩展目前的MVI56的应用，支持现有的MVI56梯形逻辑和模块配置
>>>>>型号:MVI56E-MNETC 以太网端口的配置和管理 网络搭线建桥
【英文介绍】
When you need Modbus®TCP/IP communication, the MVI56E-MNETC/MNETCXT module is definitely your best choice. The Modbus TCP/IP Enhanced Communication module supports Rockwell Automation ControlLogix Programmable Automation Controllers (PACs) for easy connection to Modicon Programmable Automation Controllers (PACs), as well as multiple Modbus TCP/IP server-compatible instruments and devices. The multi-client module improves performance by supporting up to 30 clients when supporting multiple servers on a Modbus TCP/IP network. It also supports up to 20 server connections, providing the ability to communicate with other DCS and SCADA systems. Both client and server functions can be run simultaneously, and the module can also be run as a powerful data concentrator.
The MVI56E-MNETC and MVI56E-MNETCXT have the same functions. The MVI56E-MNETCXT is used for standard process applications. The MVI56E-MNETCXT is designed for the XT™Logix control platform, enabling it to operate in extreme environments. The module can operate at higher operating temperatures and has a protective coating to protect it from harsh or caustic conditions.
MVI56E enhancements include configuration and management of EtherNet ports through modules, and CIPconnect® technology Bridges ControlNet and EtherNet/IP™ networks.
Characteristic advantage
Supports up to 30 clients and 20 servers
Faster response to multi-server applications
When one server is offline, the communication impact on other servers is minimized
The server features provide HMIs access systems, SCADA and DCS systems
RSLogix™5000 integration
The module communicates with the RSLogix 5000 using an additional Integration Instruction (AOI) or ladder file provided
No additional PAC/PLC programming is required
Easily enable/disable commands from Ladder logic
Programmatically enable various network devices and their capabilities to support multiple network device applications or recipes without reconfiguring modules
Configure and diagnose problems remotely
Easy to use Windows-based configuration software connects Ethernet /IP via remote rack, no RSLinx requirements, controls modules via 1756 or 1756-CNB interfaces, saves costs.
Allows IT to support and automate network segmentation
MVI56 is backward compatible
Help extend current MVI56 applications by adopting newer technologies to support existing MVI56 ladder logic and module configurations
>>>>>型号:MVI56E-MNETC 以太网端口的配置和管理 网络搭线建桥
