SBRIO-9607 |   单板控制器  |   用于控制和处理时序相关的任务

　　型号：SBRIO-9607

　　类别：单板控制器

　　数字I/O，RMC，667 MHz双核CPU，512MBDRAM，512MB存储

　　Zynq-7020 FPGA CompactR10单板控制器

　　sbR10-9607是一款嵌入式控制器，在单块印刷电路板(PCB)上集成了运行Nl Linux Real-Time的实时处理器、用户可重配置FPGA和VO。包括-个RIO夹层 卡(RMC)连接器。这是一种高速高带宽连接器直接访问处理器和数字VO FPGA线。sbR10-9607可轻松嵌入需要灵活

　　性、可靠性和高性能的大批量OEM应用中。该控制器具有集成的千兆位以太网、CAN、串行和USB端口以及96条3.3V数字I0线。

　　SBRIO-9607 单板控制器通常包括以下几个主要部分：

　　定时控制逻辑电路：用于控制和处理时序相关的任务。

　　指令寄存器(Register)：用于存储CPU正在执行的指令。

　　译码器：将指令翻译成具体的控制信号，以驱动其他部件执行相应的操作。

　　地址指针DPTR(Data Pointer Register)：用于存储数据存储器中数据的地址。

　　程序计数器PC(Program Counter)：由16位(8+8)寄存器构成的计数器，用于存储下一条要执行的指令的地址。

　　堆栈指针SP(Stack Pointer)：用于指示数据在堆栈中的位置，以便进行函数调用和返回等操作。

　　Model: SBRIO-9607

　　Category: Board controller

　　Digital I/O, RMC, 667 MHz dual-core CPU, 512MBDRAM, 512MB storage

　　Zynq-7020 FPGA CompactR10 Board controller

　　The sbR10-9607 is an embedded controller that combines a Real-Time processor, user-reconfigurable FPGA, and VO running Nl Linux Real-Time on a single printed circuit board (PCB). Includes - a RIO Sandwich card (RMC) connector. It is a high-speed high-bandwidth connector with direct access to processor and digital VO FPGA lines. The sbR10-9607 can be easily embedded as flexible as required

　　Performance, reliability and high performance in high volume OEM applications. The controller features integrated gigabit Ethernet, CAN, serial and USB ports and 96 3.3V digital I0 cables.

　　The SBRIO-9607 single board controller usually includes the following main parts:

　　Timing control logic circuit: Used to control and process timing related tasks.

　　Instruction Register (Register) : Used to store the instructions that the CPU is executing.

　　Decoder: Translates instructions into specific control signals to drive other components to perform corresponding operations.

　　Data Pointer Register (DPTR) : An address used to store data in the data store.

　　PC (Program Counter) : A counter consisting of 16 bit (8+8) registers that store the address of the next instruction to be executed.

　　Stack Pointer SP (Stack Pointer) : Used to indicate the position of data in the stack for operations such as function calls and returns.
