>>>>型号:SCXI-1193 多路复用开关模块
【功能描述】
SCXI-1193是一款多路复用开关模块。
SCXI-1193是一款32通道的高密度RF（射频）多路复用器开关模块，具备多种配置模式，可以配置为未端接多路复用器、外部端接多路复用器或尺寸多样的稀疏矩阵。
每种配置都能承受从DC（直流）到500 MHz以上的信号频率。
SCXI-1193模块采用高密度推进式MCX连接器进行离散但易于管理的布线，并且主要用于集成高频设备，如PXI-5404频率发生器和PXI-5112高速数字化仪。
关于其技术规格，SCXI-1193的射频载波功率范围为10瓦至500 MHz（每个频道），并且具有总RF功耗限值7 W，这个限值在整个环境工作温度范围内都有效。此外，
该模块还涉及到一些与电阻和功耗相关的特性。在继电器的使用寿命内，电阻通常保持较低，但在继电器寿命结束时，触点电阻会迅速上升至1.0ω以上。
>>>>>型号:SCXI-1193 多路复用开关模块
【英文介绍】
SCXI-1193 is a multiplex switch module.
The SCXI-1193 is a 32-channel high density RF (radio frequency) multiplexer switch module that is available in a variety of configuration modes and can be configured as
an unterminated multiplexer, an externally terminated multiplexer, or a sparse matrix of various sizes. Each configuration can withstand signal frequencies from DC (direct current)
to more than 500 MHz.
The SCXI-1193 module uses high-density propelling MCX connectors for discrete but manageable wiring and is primarily used to integrate high frequency devices such as the
PXI-5404 frequency generator and the PXI-5112 high-speed digitizer.
Regarding its technical specifications, the SCXI-1193 has an RF carrier power range of 10 watts to 500 MHz (per channel) and a total RF power consumption limit of 7 W, which
is valid over the entire ambient operating temperature range. In addition, the module also covers a number of characteristics related to resistance and power consumption.
During the life of the relay, the resistance usually remains low, but at the end of the life of the relay, the contact resistance quickly rises above 1.0ω.
