PR6426/010-140+CON021/916-240 | 传感器 |MMS6120 9100-00002-10 | CON011 9200-00001
型号:PR6426/010-140+CON021/916-240
类别:传感器
货期:3-5天/周
发货方式:顺丰/联邦
付款方式:电汇/西联
成色:全新/二手
质保:一年
、产品特点
高可靠性:PR6426/010-140+CON021/916-240 传感器具有体积小、可靠性高的特点,适用于各种恶劣的工业环境.
非接触式测量:传感器采用非接触式测量方式,可测量旋转部分与固定部分之间的间隙、轴的振动和偏心、轴的径向和轴向位移等物理量
防爆性能:传感器可用于需要防爆的环境,防爆等级可达EexibICT6/T4,符合多种国际标准,如API670、DIN45670、I010817-1等。
应用范围广:传感器可广泛应用于汽轮机监测和保护系统中MMS3000、MMS6000,以及各种涡轮机械、风机、压缩机、齿轮箱、水泵、煤梯等设备的些测知保护。
三、工作原理
PR6426/010-140+CON021/916-240 传感器与预传感器形成振荡器,衰咸幅度与传感器与被测物体之间的距离成正比,因为传感器探头靠近金属。传感器和预处理器在交付前已使用校准材料
420rM04 成套线性校准,因此在安装过程中无需校准,用户只需调整传感器和测量表面之间的气隙,直到从预处理器的输出获得所需的信号。
PR6426/010-140+CON021/916-240 | Sensor |MMS6120 9100-00002-10 | CON011 9200-00001
Model: PR6426/010-140+CON021/916-240
Category: Sensor
Delivery time: 3-5 days/week
Delivery method: SF Express/Federal
Payment method: Wire transfer/Western Union
Finish: Brand new/used
Warranty: One year
, product features
High reliability: The PR6426/010-140+CON021/916-240 sensor has the characteristics of small size and high reliability, suitable for a variety of harsh industrial environments.
Non-contact measurement: The sensor uses a non-contact measurement method to measure the gap between the rotating part and the fixed part, the vibration and eccentricity of the shaft, the radial and axial displacement of the shaft and other physical quantities
Explosion-proof performance: The sensor can be used in environments requiring explosion-proof, explosion-proof rating up to EexibICT6/T4, in line with a variety of international standards, such as API670, DIN45670, I010817-1 and so on.
Wide range of applications: the sensor can be widely used in steam turbine monitoring and protection system MMS3000, MMS6000, as well as a variety of turbine machinery, fans, compressors, gear boxes, water pumps, coal ladder and other equipment detection protection.
Third, the working principle
The PR6426/010-140+CON021/916-240 sensor forms an oscillator with the pre-sensor, and the attenuation amplitude is proportional to the distance between the sensor and the object under test, because the sensor probe is close to the metal. Sensors and preprocessors are calibrated with materials prior to delivery
The 420rM04 complete linear calibration so that no calibration is required during installation and the user simply adjusts the air gap between the sensor and the measuring surface until the desired signal is obtained from the output of the preprocessor.
