>>>型号:1336-SN-SP10A 逆变器缓冲器 用于自动化系统 兼容1336可调频交流驱动器
【功能描述】
1336-SN-SP10A是一种逆变器缓冲器,专门用于1336 Plus、Plus II、Impact和Force驱动器,特别兼容1336可调频交流驱动器。它属于2级装配组件,是一种备件项目。每个驱动器使用三个这样的缓冲器套件。
1336-SN-SP10A这种缓冲器印刷电路板(PCB)主要用于框架E或输出功率为150、200、250和X300HP的驱动器。在驱动器的内部,缓冲板安装在驱动器主机架内部,位于转换器托架中桥式散热器的一侧。
在更换此板时,需要切断驱动器的电源并锁定以防止访问。即使驱动器的电源被移除,也不要立即触摸组件,因为它有电容器可以短时间储存电压。因此,在继续操作之前,需要测量TB1端子块上的+DC和-DC,确保安全。同时,
还需要卸下位于81、82和83端子的导线,并相应地标记电线。
1336-SN-SP10A可能还涉及其他应用领域或具有其他功能特性,例如与高速无线PROFIBUS DP通信网关的配合使用,提供高效、强大的空中无线协议,支持多达13个通道和一个有线PROFIBUS主或从接口端口。这些特性使得它
在现场设备的数据传输和诊断方面具有较高的效率和可靠性。
>>>>型号:1336-SN-SP10A 逆变器缓冲器 用于自动化系统 兼容1336可调频交流驱动器
【英文介绍】
The 1336-SN-SP10A is an inverter buffer designed specifically for the 1336 Plus, Plus II, Impact, and Force drives, with special compatibility with Allen-Bradley's 1336 adjustable AC drives. It is a class 2 assembly
component and is a spare parts item. Each drive uses three of these buffer suites.
1336-SN-SP10A This buffer printed circuit board (PCB) is mainly used in frame E or drives with output power of 150, 200, 250 and X300HP. On the inside of the drive, the buffer plate is mounted inside the drive
frame, on the side of the bridge radiator in the converter carriage.
When replacing this board, the power to the drive needs to be cut off and locked to prevent access. Even if the power supply to the drive is removed, do not touch the component immediately because it has capacitors
that can store voltage for a short time. Therefore, before proceeding, it is necessary to measure the +DC and -DC on the TB1 terminal block to ensure safety. At the same time, the wires at terminals 81, 82, and 83 need
to be removed and the wires marked accordingly.
The 1336-SN-SP10A May also be involved in other application areas or have other functional features, such as use in conjunction with a high-speed wireless PROFIBUS DP communication gateway to provide an efficient
and powerful over-the-air wireless protocol supporting up to 13 channels and a wired PROFIBUS master or slave interface port. These characteristics make it highly efficient and reliable in data transmission and diagnosis of field equipment.
