>>>>>型号:140CRP93100 头端适配器 带单根电缆
【功能描述】
140CRP93100单电缆RIO头适配器模块的亮点
Modicon量子自动化平台
体系结构类型 - 远程 I/O
单根电缆
S908总线
在量子 CPU 头端模块中连接
介绍: Quantum RIO head adaptor (max. 1) (1)
电缆 - 单同轴电缆
所需总线电流 – 600 mA
功耗 - 3 W
优势
Modicon 140CRP93100是以太网RIO架构的一个组成部分。它是一个简单的菊花环的一部分,也称为菊花火车环。简单的菊花环由本地昆腾以太网分接器制成,昆腾或Modicon X80以太网RIO分接器包含CRA分接器,使用140CRP93100作为RIO头端适配器。
如何使用 140CRP93100
您必须安装和使用 MA0185100 T 型连接器 10,因为系统上的每个 I/O 分支都需要它。之所以需要 T 型连接器,是因为它允许您将跌落与主干电缆电气隔离,并保护系统免受任何可能的阻抗匹配不正确的影响,除了阻抗问题外,它还是可能的电缆断开的安全网。在干线电缆和每个 I/O 分线之间,所需的最小信号强度为 14 dB。
>>>>>型号:140CRP93100 头端适配器 带单根电缆
【英文介绍】
140CRP93100 Single cable RIO Head adapter module highlights
Modicon quantum automation platform
Architecture Type - Remote I/O
Single cable
The S908 bus
Connect in the quantum CPU headend module
Description: Quantum RIO head adaptor (max. 1) (1)
Cable - Single coaxial cable
Required bus current - 600 mA
Power consumption - 3 W
advantage
Modicon 140CRP93100 is an integral part of the Ethernet RIO architecture. It is part of a simple chrysanthemum ring, also known as the chrysanthemum train ring. The simple Daisy ring is made from a native Quinten Ethernet adapter, a Quinten or Modicon X80 Ethernet RIO adapter containing a CRA adapter, using 140CRP93100 as the RIO headend adapter.
How to use 140CRP93100
You must install and use the MA0185100 T-connector 10, as it is required for every I/O branch on the system. The T-connector is needed because it allows you to electrically isolate the drop from the backbone cable and protect the system from any possible impedance mismatch, in addition to impedance issues, it is a safety net for possible cable disconnection. Between the trunk cable and each I/O branch, the required minimum signal strength is 14 dB.
