>>>>>型号:CC-PAIN01 16个通道带HART的高电平模拟输入
【功能描述】
制造商:霍尼韦尔
产品编号:CC-PAIN01
产品类型:带HART的模拟输入
输入/输出型号:CC-PAIN01 -带HART的高电平模拟输入
IOTA模型:
CC-TAIX51:非冗余6英寸
CC-TAIX61:冗余12英寸
输入类型:电流(双线或自供电变送器)
输入通道:16个通道(均为单端)
共模抑制比，直流至60 Hz (500？源不平衡):70分贝
共模电压，直流至60 Hz : -6至+5 V峰值
模数转换器分辨率:16位
输入范围:仅4-20 mA(通过200ω)
60 Hz时的正常模式抑制比:19 dB
正常模式滤波器响应:单极RC，-3 dB(6.5Hz)
最大正常模式输入:30伏
串扰，直流至60 Hz(通道间):-60 dB
输入扫描速率:50毫秒
硬件精度(@ CMV = 0 V):
满量程的0.075%(23.5±2°C)
满量程的0.15%(0至60°C)
>>>>>型号:CC-PAIN01 16个通道带HART的高电平模拟输入
【英文介绍】
Manufacturer: Honeywell
Product Number :CC-PAIN01
Product Type: Analog input with HART
Input/Output Model :CC-PAIN01 - High level analog input with HART
IOTA Model:
CC-TAIX51: Non-redundant 6 inches
CC-TAIX61: Redundant 12 inches
Input type: Current (two-wire or self-powered transmitter)
Input channels :16 channels (all single-ended)
Common-mode rejection ratio, DC to 60 Hz (500? Source imbalance):70 dB
Common mode voltage, DC to 60 Hz: -6 to +5 V peak
Adc resolution :16 bits
Input range: only 4-20 mA(through 200ω)
Normal mode rejection ratio at 60 Hz :19 dB
Normal mode filter response: unipolar RC, -3 dB(6.5Hz)
Max Normal mode input :30 volts
Crosstalk, DC to 60 Hz(between channels):-60 dB
Input scan rate :50 ms
Hardware accuracy (@CMV = 0V):
0.075% of full scale (23.5±2°C)
0.15% of full scale (0 to 60°C)
