>>>>>型号:F8650X 输入/输出模块 四位字母数字显示
【功能描述】
中心模块诊断显示
-四位字母数字显示;
-两个led一般显示错误(CPU为中央模块,IO为可测试
输入/输出模块),
-两个拨动开关请求详细的错误信息;
- ACK按钮复位错误指示;
在失败停止ACK行为像重新启动系统。
有关诊断显示和错误代码列表的进一步信息,请参阅文档“操作系统BS 41q/51q的功能”(也在ELOP II CD上)。
启动和维护注意事项
-缓冲电池寿命(无电压馈电):
在TA = 25℃下1000天
温度为60℃,温度为200天
—建议最迟在6后更换缓冲电池(运行中的CPU)
年,或在三个月内显示BATI
锂电池,如CR 2477N型,HIMA零件号44 0000018)
-查询巴士站号码。和交换机S1的传输速率,以便正确设置
-重要提示:当F 8650升级到F 8650X模块时,风扇的概念也必须改变
被改变
>>>>>型号:F8650X 输入/输出模块 四位字母数字显示
【英文介绍】
Diagnostic display of the central module
– Four digit alphanumerical display,
– two LEDs for the general display of errors (CPU for the central modules, IO for the testable
input/output modules),
– two toggle switches to request detailed error information,
– push-button ACK resets the error indication;
in failure stop ACK behaves like restarting the system.
For further information on the diagnostic display and lists of error codes, refer to the documentation "Functions of the operational system BS 41q/51q" (also on ELOP II CD).
Notes for start-up and maintenance
– Lifetime of the buffer battery (without voltage feeding):
1000 days at TA = 25 °C
200 days at TA = 60 °C
– It is recommended to change the buffer battery (CPU in operation) at the latest after 6
years, or with display BATI within three months
(Lithium battery, e.g. type CR 2477N, HIMA part no. 44 0000018)
– Check the bus station no. and transmission rate at switch S1 for correct settings
– Important: When upgrading an F 8650 to an F 8650X module the fan concept has also to
be changed
