IS200TVIBH2BBB
IS200TVIBH2BBB

IS200TVIBH2BBB 振动终止板 用于控制和包含数据

>>>>>型号:IS200TVIBH2BBB 振动终止板 用于控制和包含数据 【功能描述】 该IS200TVIBH2BBB由通用电气制造和制造,是该公司Speedtronic Mark VI涡轮机控制线的一部分。Speedtronic系统用于控制从大型到小型的工业蒸汽和燃气轮机系统的功能和操作。MKVI易于集成,提供控制和保护功能。该IS200TVIBH2BBB用作

电话/Phone:18859254943 (微信同号)

邮箱/Email:sales@ygdcs.com

QQ:3561040004

产品详情

>>>>>型号:IS200TVIBH2BBB 振动终止板 用于控制和包含数据





【功能描述】





该IS200TVIBH2BBB由通用电气制造和制造,是该公司Speedtronic Mark VI涡轮机控制线的一部分。Speedtronic系统用于控制从大型到小型的工业蒸汽和燃气轮机系统的功能和操作。MKVI易于集成,提供控制和保护功能。

该IS200TVIBH2BBB用作振动终止板。它由安装在其表面的多个集成电路构建而成,用于控制和包含数据。该板还包括电阻器和电容器等典型元件。此外,它还在电路板的一侧有14个插头连接器。

该IS200TVIBH2BBB有两个大接线端子,占用一个长板边缘。这些接线端子采用螺钉连接,分为两条线。每个单独的螺钉连接都有编号。这将使用户能够更好地维护和跟踪所有电路板连接。

IS200TVIBH2BBB上的其他电路板组件包括母头D型外壳连接器、电感器和跳线开关。跳线放置在靠近板中心的一条线上。它们成对放置。可以更改或重置跳线,以控制电路板中电路的布线方式。有关详细信息,请参阅原始GE文档。


 >>>>>型号:IS200TVIBH2BBB 振动终止板 用于控制和包含数据



英文介绍



The IS200TVIBH2BBB is manufactured and manufactured by General Electric as part of the company's Speedtronic Mark VI turbine control line. Speedtronic systems are used to control the function and operation of industrial steam and gas turbine systems from large to small. MKVI is easy to integrate and provides control and protection.

The IS200TVIBH2BBB is used as a vibration termination board. It is built from multiple integrated circuits mounted on its surface to control and contain data. The board also includes typical components such as resistors and capacitors. In addition, it also has 14 plug connectors on the side of the board.

The IS200TVIBH2BBB has two large terminals occupying a long board edge. These terminals are connected by screws and are divided into two wires. Each individual screw connection is numbered. This will enable users to better maintain and track all board connections.

Other board components on the IS200TVIBH2BBB include female D-housing connectors, inductors, and jumper switches. The jumper is placed on a line near the center of the board. They are placed in pairs. The jumper can be changed or reset to control how the circuit in the board is routed. See the original GE documentation for more information.

>>>>>型号:IS200TVIBH2BBB 振动终止板 用于控制和包含数据

水波纹风名片设计 (1702363063)_0.jpg

水波纹风名片设计 (1702363063)_1.jpg
