IC695CEP001 | 以太网接口模块 | IC695ALG412| IC695ALG112

　　型号：IC695CEP001

　　类别：以太网接口模块

　　成色：全新/非全新

　　质保：一年

　　IC695CEP001 以太网接口模块是一种网络通信设备，它通常配备标准的RJ45以太网接口和RS232/485串口，以确保与各类PLC设备的兼容连接。该模块的主要功能包括实时数据采集、支持工业标准协议以及与其他设备和系统的无缝集成。

　　IC695CEP001 以太网接口电路主要由MAC控制器和物理层接口(PHY)两大部分构成。一般32位处理器内部实际上已包含了以太网MAC控制，但并未提供物理层接口，因此需外接一片物理层芯片以提供以太网的接入通道。以太网物理层接口器件的主要功能包括物理编码子层、物理媒体附件、双绞线物理媒体子层、10BASE-TX编码/解码器和双绞线媒体访问单元等。

　　特征

　　扫描远程节点内的所有模块(输入和输出扫描)

　　在用户指定的生产周期将PROFINET网络上的数据发布到PROFINE IO控制器

　　在客户指定的生产期间从PROFINET网络上的PROFINET IO控制器接收数据。

　　管理PROFINET IO控制器与远程节点内模块之间的PROFINET通信和模块配置。

　　在通信丢失时管理 I/O 的状态

　　将故障信息(警报、诊断等)发布到 PROFINET IO 控制器

　　IC695CEP001 | Ethernet interface module | IC695ALG412| IC695ALG112

　　Model: IC695CEP001

　　Category: Ethernet interface module

　　Finish: New/not new

　　Warranty: One year

　　IC695CEP001 Ethernet interface module is a network communication device, which is usually equipped with a standard RJ45 Ethernet interface and RS232/485 serial port to ensure compatible connection with various PLC devices. Key features of the module include real-time data acquisition, support for industry standard protocols, and seamless integration with other devices and systems.

　　IC695CEP001 Ethernet interface circuit is mainly composed of MAC controller and physical layer interface (PHY) two parts. Generally, 32-bit processors actually contain Ethernet MAC control inside, but do not provide physical layer interfaces, so an external physical layer chip is needed to provide Ethernet access channels. The main functions of Ethernet physical layer interface devices include physical coding subelayer, physical media accessories, twisted pair physical media subelayer, 10BASE-TX encoding/decoder and twisted pair media access unit.

　　trait

　　Scan all modules within the remote node (input and output scanning)

　　The data on the PROFINET network is published to the PROFINE IO controller during the user-specified production cycle

　　Receive data from the PROFINET IO controller on the PROFINET network during the production period specified by the customer.

　　Manages PROFINET communication and module configuration between the PROFINET IO controller and modules within the remote node.

　　Manage the state of I/O when communication is lost

　　Publish fault information (alerts, diagnostics, etc.) to the PROFINET IO controller
