>>>>>型号:IS200TBCIH2CAA 单板元器件 具有降低高频噪声
【功能描述】
IS200TBCIH2CAA是GE公司生产的单板元器件。
IS200TBCIH2CAA是一个小板设计为马克六系统的终端板。Mark
VI是Speedtronic Mark系列中用于控制可编程逻辑控制器（PLC）或分布式控制系统（DCS）的微处理器。
IS200TBCIH2CAAAA是一款TBCI(Contact Input Group Isolation)端子板。该板由两个端子块和三个电缆连接器组成。端子排(TB1/TB2)各有24个螺钉连接，或12个触点。连接到这些触点使用多达12根AWG线。这些板是屏障型端子块，可以从板上拔出进行维护。线缆连接器为DC-37(母头)连接器，带锁扣。这些标为JT1/JS1/JR1。电路板有两个插头连接器用于电源输入。这些标签是JE1/JE2。电路板由金属框架包围，金属框架包括屏蔽端子带/排。
IS200TBCIH2CAAAA具有降低高频噪声和抑制每个输入浪涌的滤波器。一对端子用于每个输入，其中一个螺钉提供正直流电源，第二个点提供返回到电路板。前21个输入的电流负载为每点2.5 mA。最后三个有10毫安的负载。主板没有硬件设置或跳线。诊断信息可以使用GE出版物GEH-6421找到。本出版物也有更多关于电路板安装和操作的信息。
单板元器件是印制电路板组装中的元器件。
单板元器件是构成电路的基础，是电子设备中不可或缺的一部分。单板元器件的种类繁多，包括电阻、电容、电感、二极管、三极管、场效应管、集成电路等。
单板元器件的选用和设计需要考虑电路的性能、功耗、尺寸、成本等多个因素。同时，单板元器件的制造和测试也需要严格的质量控制，以确保其质量和可靠性。
>>>>>型号:IS200TBCIH2CAA 单板元器件 具有降低高频噪声
【英文介绍】
The IS200TBAIH1CCC is a microprocessor expansion board manufactured by General Electric (GE).
IS200TBAIH1CCC is a Mark developed by the General Electric Company
VI series of component devices. Mark
VI is a microprocessor in the Speedtronic Mark family for controlling programmable logic controllers (PLCS) or distributed control systems (DCS).
The IS200TBAIH1CCC is a device known as an analog input card. This is a PCB(printed circuit board). The IS200TBAIH1CCC is a Mark VI series component device developed by General Electric. The Mark VI is a version of the Speedtronic Mark series. These systems are used to manage and automate the operation of industrial gas and steam turbines. The Mark VI and other series of Mark lines are used worldwide in a variety of industries.
IS200TBAIH1CCC is a long printed circuit board with a wide variety of electronic components. The largest pieces on the IS200TBAIH1CCC are two long black terminal blocks that are fixed to the left edge. These terminal blocks are identified as TB1 and TB2. Both terminal blocks may contain up to twelve (12) silver metal terminals that look like cubes. Sitting opposite the IS200TBAIH1CCC are three (3) long jack connector ports. Connector ports Each has thirty-seven (37) small female connectors that can be used to attach additional components or boards to the IS200TBAIH1CCC. Connectors are identified as JT1, JS1, and JR1. The center of the IS200TBAIH1CCC is occupied by a variety of different components. There are at least 10 transistors on the IS200TBAIH1CCC, most of them arranged in the middle. Ten (10) variable resistors or potentiometers are also aligned along the center of the IS200TBAIH1CCC. Twenty (20) pairs of jumper pins can be seen on IS200TBAIH1CCC. Each pair of jumper pins is connected by a red jumper. Connecting the pin pairs together can regulate the function of the IS200TBAIH1CCC.
