IS200STAIH1ABB  | 印刷电路板 |  可变电阻器

产品参数:

　　型号：IS200STAIH1ABB

　　输入电压:24V DC

　　-输入电流:1A

　　通道数:16

　　-工作温度:-40℃~70℃℃

　　安装类型:DIN导轨

　　产品描述

　　IS200STAIH1ABB是一种称为DINrail卡的设备。这是印刷电路板或PCB的一种形式。IS200STAIH1ABB是通用电气或GE的Mark VI系列的一个组件。Mark VI 是 Mark 系列燃气和蒸汽工业涡轮机控制装置中包含的几个系列之一。

　　IS200STAIH1ABB是一种相对较小的印刷电路板，具有许多不同的电子元件。沿着IS200STAIH1ABB底部边缘是一个大型绿色接线端子。该接线端子可以包含二十四 (24) 个或更多称为端子的小金属部件。沿着IS200STAIH1ABB的另一侧是一个银色和黑色的连接器端口。此连接器端口可用于将其他部件连接到IS200STAIH1ABB。十四 (14) 个电位器，也称为可变电阻器，可以在IS200STAIH1ABB的不同位置找到。其中四 (4) 个电位器垂直排列在IS200STAIH1ABB的右上角。剩下的十 (10) 个电位器在IS200STAIH1ABB中心附近水平排列。位于此行上方的是另一行组件。该系列具有十 (10) 个小型晶体管。每两 (2) 个晶体管之间是一对红色跳线。每个跳线用于将至少两个金属跳线引脚连接在一起。

　　Product parameters:

　　Model: IS200STAIH1ABB

　　Input voltage :24V DC

　　- Input current :1A

　　Number of channels :16

　　- Operating temperature :-40 ° C ~70 ° C

　　Mounting type :DIN rail

　　Product description

　　The IS200STAIH1ABB is a device called a DINrail card. This is a form of printed circuit board or PCB. The IS200STAIH1ABB is a component of the General Electric or GE Mark VI series. The Mark VI is one of several families included in the Mark Series of gas and steam industrial turbine control units.

　　The IS200STAIH1ABB is a relatively small printed circuit board with many different electronic components. Along the bottom edge of the IS200STAIH1ABB is a large green terminal. The terminal may contain twenty-four (24) or more small metal parts called terminals. Along the other side of the IS200STAIH1ABB is a silver and black connector port. This connector port can be used to connect other components to the IS200STAIH1ABB. Fourteen (14) potentiometers, also known as variable resistors, can be found at various locations in the IS200STAIH1ABB. Four (4) of these potentiometers are arranged vertically in the upper right corner of the IS200STAIH1ABB. The remaining ten (10) potentiometers are arranged horizontally near the IS200STAIH1ABB center. Above this row is another row of components. The series has ten (10) small transistors. Between every two (2) transistors are a pair of red jumpers. Each jumper is used to connect at least two metal jumper pins together. The IS200STAIH1ABB contains several square black diodes
