IC697CPM915RR  |   单插槽可编程CPU模块

型号：IC697CPM915RR

　　模块类型： 浮点 CPU

　　插槽数量： 1 (单插槽)

　　点数： 12K 输入和输出(任意混音)

　　支持： IC660/IC661 I/O 和 IC697 I/O

　　所需电流： 2.8 安培标称值

　　IC697CPM915RR 是由GE Fanuc制造的90-70系列中的32 MHz，32位浮点中央处理器。 该 CPU 由 MS-DOS 或 Windows 软件编程，可实时控制机器、流程和物料搬运。它通过机架安装的背板与 I/O 和智能选件模块进行通信。部分功能包括单插槽 CPU、1 MB 同插槽电池备份存储器、12K 混合输入和输出、高达 8K 模拟 I/O 以及可配置的数据/程序存储器。该IC697CPM915支持浮点计算，每个布尔函数的执行时间为 0.4 微秒。

　　IC697CPM915RR 支持多种选件模块，包括 IC697 系列中的所有 IC697 LAN 接口模块、多个协处理器模块、IC660/661 总线控制器和分立/模拟 I/O 模块。 IC697CPM915通过闪存存储操作系统固件;但是，此模块不支持存储用户程序。固件无需拆卸或更换EPROM即可更新。固件更新是通过将兼容的 PC 连接到串行端口并运行提供的 Loader 软件来进行的。

　　IC697CPM915RR 该模块可以通过控制三位 RUN/STOP 开关或通过远程连接的编程器和相应的软件来操作。程序/配置数据通过密码或使用按键开关手动锁定。如果密钥是“受保护的”，则数据只能由仅与BTM(总线发射器模块)并联的编程器进行调整。模块正面的四个绿色 LED 显示 CPU 状态。IC697CPM915应使用提供的手册正确安装。电池可以连接到任一连接器。拨动开关应处于 STOP 位置，按键开关应处于 Memory Protection OFF 位置。机架电源也应关闭。然后可以将模块安装在插槽 1 中并启动电源。

　　Model: IC697CPM915RR

　　Module type: floating point CPU

　　Number of slots: 1 (single slot)

　　Points: 12K input and output (any mix)

　　Support: IC660/IC661 I/O and IC697 I/O

　　Required current: 2.8 amps nominal value

　　The IC697CPM915RR is a 32 MHz, 32-bit floating point CPU in the 90-70 series manufactured by GE Fanuc. The CPU is programmed by MS-DOS or Windows software to control machines, processes, and material handling in real time. It communicates with the I/O and smart option modules through a rack-mounted backplane. Some features include a single-slot CPU, 1 MB of same-slot battery backup memory, 12K mixed input and output, up to 8K analog I/O, and configurable data/program memory. The IC697CPM915 supports floating-point calculations and has an execution time of 0.4 microseconds per Boolean function.

　　The IC697CPM915RR supports a variety of optional modules, including all IC697 LAN interface modules in the IC697 family, multiple coprocessor modules, IC660/661 bus controllers, and discrete/analog I/O modules. IC697CPM915 stores operating system firmware via flash memory; However, this module does not support storing user programs. Firmware can be updated without removing or replacing the EPROM. Firmware updates are done by connecting a compatible PC to a serial port and running the provided Loader software.

　　IC697CPM915RR The module can be operated by controlling the three-digit RUN/STOP switch or through a remotely connected programmer and corresponding software. Program/configuration data is locked manually with a password or by using a key switch. If the key is "protected", the data can only be adjusted by a programmer that is only in parallel with the BTM (Bus transmitter module). Four green leds on the front of the module show the CPU status. The IC697CPM915 should be properly installed using the manual provided. The battery can be connected to either connector. The toggle switch should be in the STOP position and the key switch should be in the Memory Protection OFF position. The rack power should also be turned off. You can then install the module in slot 1 and start the power supply.
