IC693CPU364 | 90-30 系列产品系列  | 控制器模块

　　IC693CPU364是 90-30 系列产品系列中的控制器模块。该控制器由 GE Fanuc 自动化制造，具有一 (1) 个以太网接口、240KB 用户内存、80386EX 处理器，处理器速度为 25 MHz，布尔触点的典型扫描速率为每 1K 逻辑 0.22 毫秒。

　　该控制器支持多达 2,048 个离散输入、2,048 个离散输出、多达 1,280 位内部离散全局存储器、4096 个内部线圈、256 位临时输出线圈、可配置模拟输入，使用 Logicmaster 软件以 128 字为增量，从 128 字增加到 16,384 字，使用 Control 版本 2.2 从 128 字增加到 32,640 字，模拟输出可使用 Logicmaster 编程软件以 128 字的增量从 128 字配置到 16,384 字和 128使用 Control 版本 2.2 时，增加到 32,640 字。

　　IC693CPU364通常称为 CPU 364。它是一个单槽宽控制器模块，处理器类型为 80386EX，处理器速度为 25 MHz，布尔触点的扫描速率为每 1K 逻辑 0.22 ms(典型值)。它有一个 240KB 的嵌入式用户内存，可以根据配置的 %R、%AI 和 %AQ 变量和寄存器进行配置。它有一 (1) 个以太网通信端口，用于编程和通信。该控制器也可以通过内置的 RS485 通信端口进行通信，该端口安装在位于底板最左侧插槽的电源上。此控制器最多支持八 (8) 个基板，其中一 (1) 个基板是 CPU 基板，七 (7) 个是远程 I/O 基板。

　　The IC693CPU364 is a controller module in the 90-30 series product family. Manufactured by GE Fanuc Automation, the controller features one (1) Ethernet interface, 240KB of user memory, an 80386EX processor with a processor speed of 25 MHz and a typical sweep rate of 0.22 ms per 1K logic for Boolean contacts.

　　The controller supports up to 2,048 discrete inputs, 2,048 discrete outputs, up to 1,280 bits of internal discrete global memory, 4096 internal coils, 256-bit temporary output coils, configurable analog inputs in 128-word increments using Logicmaster software. Increased from 128 words to 16,384 words, using Control version 2.2 increased from 128 words to 32,640 words, Analog output can be configured in 128-word increments from 128 words to 16,384 words using Logicmaster programming software and increased to 32,640 words when 128 is used with Control version 2.2.

　　IC693CPU364 is commonly referred to as CPU364. It is a single slot wide controller module with a processor type of 80386EX, a processor speed of 25 MHz, and a sweep rate of 0.22 ms per 1K logic for Boolean contacts (typical value). It has a 240KB embedded user memory that can be configured according to the configured %R, %AI, and %AQ variables and registers. It has one (1) Ethernet communication port for programming and communication. The controller can also communicate via the built-in RS485 communication port, which is installed on the power supply located in the leftmost slot of the baseboard. This controller supports up to eight (8) substrates, of which one (1) substrate is a CPU substrate and seven (7) is a remote I/O substrate.
