IC693PBM200  |  主模块  | 90-30 系列控制器

　IC693BPM200 是一个 Profibus 主模块，是 90-30 系列控制器平台的一部分，该平台以前来自 GE Fanuc，现在被 Emerson Automation 收购。该模块是支持Profibus通信协议的可选通信模块。它带有一 (1) 个 Profibus Master 端口，支持以菊花链拓扑形式与 Profibus 网络通信，另一个 RS232 服务端口可用于下载配置和固件升级。

　　IC693BPM200是一个单插槽模块，可安装到 CPU 底板、扩展或远程底板。它支持多达 125 个 Profibus DP 从站的通信，从而实现远程 I/O 架构并与其他设备(如网关、HMI、SCADA 和其他设备)进行通信。对于远程 I/O 功能，每个 Profibus 从站能够接收 244 字节的输入数据并发送 244 字节的输出数据。它支持同步和冻结配置，并可配置为从 9600 Kbaud 到 12MBaud 的所有 Profibus 标准传输速率。它遵循菊花链拓扑结构，因为该协议源自 RS485 电气标准，其两端(特别是网络的节点 1 和最后一个节点)通过终端电阻闭合。它还带有 SYS 和 COM 状态 LED，用于描述活动通信和设备操作。

　　此模块使用 CIMPLICITY Machine Edition Logic Developer 2.6 或更高版本进行配置。它可以与 90-30 系列 CPU 一起使用，例如 CPU 311/313/323、331、341,350、352、360、363、363 和 364。对于大多数应用和控制系统，此模块适用的 CPU 版本为 V8.00，但如果打算用于大型应用，则可能需要 CPU 版本 10.60 或更高版本。

　　GE Fanuc IC693PBM200 Profibus DP 主模块通信卡是一种固态通信卡，专为 GE 90-30 系列可编程逻辑控制器而设计和制造。它作为PLC和PROFIBUS DP网络之间的主要通信接口，使PLC能够连接到网络并与现场设备、其他控制器、通信平台和许多其他类型的设备建立数据交换。使用该模块，可以从单个Fanuc PLC控制多达125个PROFIBUS DP从站单元，该模块能够从网络接收244字节的输入，并发送244字节的输出命令作为响应。

　　The IC693BPM200 is a Profibus master module that is part of the 90-30 series controller platform, formerly from GE Fanuc and now acquired by Emerson Automation. This module is an optional communication module that supports Profibus communication protocol. It comes with one (1) Profibus Master port that supports communication with the Profibus network in a Daisy chain topology, and another RS232 service port that can be used to download configurations and firmware upgrades.

　　The IC693BPM200 is a single-slot module that can be installed on CPU backboards, extensions, or remote backboards. It supports communication of up to 125 Profibus DP slaves, enabling remote I/O architectures and communication with other devices such as gateways, Hmis, SCADA, and others. For remote I/O functions, each Profibus slave station is capable of receiving 244 bytes of input data and sending 244 bytes of output data. It supports sync and freeze configurations and can be configured for all Profibus standard transfer rates from 9600 Kbaud to 12MBaud. It follows a Daisy chain topology, as the protocol is derived from the RS485 electrical standard, and its two ends (especially node 1 and the last node of the network) are closed by terminal resistors. It also comes with SYS and COM status leds for describing active communication and device operation.

　　This module is configured using CIMPLICITY Machine Edition Logic Developer 2.6 or later. It can be used with 90-30 series cpus, such as cpus 311/313/323, 331, 341,350, 352, 360, 363, 363, and 364. For most applications and control systems, the CPU version for this module is V8.00, but if you intend to use it for large applications, you may need CPU version 10.60 or higher.

　　The GE Fanuc IC693PBM200 Profibus DP Master Module communication card is a solid-state communication card designed and manufactured for the GE 90-30 series programmable logic controllers. It acts as the main communication interface between the PLC and the PROFIBUS DP network, enabling the PLC to connect to the network and establish data exchange with field equipment, other controllers, communication platforms and many other types of equipment. Up to 125 PROFIBUS DP slave station units can be controlled from a single Fanuc PLC using the module, which is capable of receiving 244 bytes of input from the network and sending 244 bytes of output commands in response.
