>>>>>型号:IS200TREGH1B Mark VI主板 跳闸紧急终止板
【功能描述】
通用电气(General Electric)或通用电气(GE)创建了IS200TREGH1B作为跳闸紧急终止板。这是一种为Mark VI系列制造的印刷电路板或PCB。Mark VI 是通用电气 Mark 系列的最新系列。这些系列是为蒸汽轮机和燃气轮机的运行和自动化而设计的。
该设备上最引人注目的组件是一系列正方形的变压器。这些变压器由透明塑料和银线覆盖。这些盖板包含有关组件的信息,例如部件号和电压。这些变压器中有十二 (12) 个位于IS200TREGH1B上的两条垂直线,每条垂直线有六 (6) 个变压器。两 (2) 个大型黑色接线端子占据了IS200TREGH1B左边缘的空间。接线端子共有四十八 (48) 个端子,由银色金属制成。这些端子在两 (2) 个接线端子之间平均分配为二十四 (24) 个。该IS200TREGH1B包含许多称为金属氧化物压敏电阻或MOV的组件。这些 MOV 是圆形和纯红色的。它们被放置在IS200TREGH1B的边缘。三 (3) 个白色跳线端口已放置在IS200TREGH1B的顶部边缘。这些端口之间总共有十七 (17) 个端口。左侧的连接器具有三个端口,标识为 JH1。中间的连接器包含十二个标识为 J2 的端口,右侧的最后一个连接器包含标识为 J1 的两 (2) 个端口。
>>>>>型号:IS200TREGH1B Mark VI主板 跳闸紧急终止板
【英文介绍】
General Electric or GE created the IS200TREGH1B as a trip emergency termination board. This is a printed circuit board or PCB manufactured for the Mark VI series. The Mark VI is the latest in the General Electric Mark series. These series are designed for the operation and automation of steam and gas turbines.
The most striking component on the device is a series of square transformers. These transformers are covered with transparent plastic and silver wire. These cover plates contain information about the component, such as part number and voltage. There are twelve (12) of these transformers located on two vertical lines on the IS200TREGH1B, each of which has six (6) transformers. Two (2) large black terminals occupy the space on the left edge of the IS200TREGH1B. There are forty-eight (48) terminals, made of silver metal. These terminals are evenly divided into twenty-four (24) terminals between two (2) terminals. The IS200TREGH1B contains a number of components called metal oxide varistors or MOV. These MOV are round and solid red. They are placed on the edge of IS200TREGH1B. Three (3) white jumper ports have been placed on the top edge of the IS200TREGH1B. There are a total of seventeen (17) ports between these ports. The connector on the left has three ports, identified as JH1. The middle connector contains twelve ports identified as J2, and the last connector on the right contains two (2) ports identified as J1.
