>>>>>型号:A6110 低差稳压器 有固定输出两种 电压
【功能描述】
A6110是一种低差稳压器
输入电压从2.5V到6V，输出1a
负载电流。A6110有固定输出两种
电压。固定类型的输出电压为
预设在内部修整电压1V,1.2V，
1.3v、1.5v、1.8v、2.5v、2.7v、2.8v、2.85v、3.0v、
3.2V、3.3V、5V或可作配选
输出范围从1V到5V，增量50mV。
A6110由一个电压基准单元和一个电压基准单元组成
误差放大器，电阻网设置输出电压，
一个过流限流电路和一个
过热而关机电路。
输出电流高达1A
70uA工作电源电流
优异的线路稳压:0.05%/V
低Dropout:350mV 1A(VOUT=3.3V)
高电源抑制比
宽工作电压范围:2.5V~6.0V
整机1V至5V出厂预设输出
●高精度:±2%
内置自动放电功能
500mA冲击电流限制
可折叠限制电流保护
热关机保护
可提供TO252-3和SOT223-3封装
>>>>>型号:A6110 低差稳压器 有固定输出两种 电压
【英文介绍】
The A6110 is a low differential voltage regulator
Input voltage from 2.5V to 6V, output 1a
Load current. The A6110 comes in two fixed outputs
Voltage. The output voltage of the fixed type is
Preset internal trimming voltage 1V,1.2V,
1.3v, 1.5v, 1.8v, 2.5v, 2.7v, 2.8v, 2.85v, 3.0v,
3.2V, 3.3V, 5V or optional
Output ranges from 1V to 5V in 50mV increments.
The A6110 consists of a voltage reference unit and a voltage reference unit
Error amplifier, resistor net sets output voltage,
One overcurrent limiting circuit and one
Overheat and shutdown circuit.
Output current up to 1A
70uA working power supply current
Excellent line voltage regulation :0.05%/V
Low Dropout:350mV 1A(VOUT=3.3V)
High power rejection ratio
Wide operating voltage range :2.5V~6.0V
Machine 1V to 5V factory preset output
● High precision :±2%
Built-in automatic discharge function
500mA impulse current limit
Foldable limiting current protection
Thermal shutdown protection
Available in TO252-3 and SOT223-3 packages
