>>>>>型号:3500/42M 近震器/地震监测仪 （4） 通道监视器
【功能描述】
特征：
（4） 通道监视器
接受来自接近传感器和地震传感器的输入
机械保护
提供必要的机器信息
GE / Bently Nevada 3500/42M 系列近似/地震监测仪是四通道监测器，接受来自接近和地震传感器的输入，对信号进行调节以提供各种振动和位置测量，并将调节信号与用户可编程报警进行比较。
您可以使用 3500 机架配置软件对每个通道进行编程，以执行以下功能：径向振动、推力位置、差动膨胀、偏心率、REBAM、加速度、速度、绝对轴和圆形接受区域。
3500/42M 接近/地震监测仪的主要目的是通过连续将监测参数与配置的报警设定值进行比较来提供机械保护，以驱动报警。这些模块还为操作和维护人员提供必要的机器信息。
监控通道成对设置，最多可以同时执行两个指定的功能。例如，通道 1 和 2 可以执行一个功能，而通道 3 和 4 执行另一个或相同的功能。
Proximitor Seismic Monitor 通过实时比较监测参数与选定的警报设置点并触发警报来保护机械。它通知操作和维护人员有关关键机器信息的信息。
根据安排，每个通道通常会调节其输入信号以产生一组静态值。可以为任何当前静态值建立警报设置点，也可以为其中任意两个设置危险设置点。
使用机架配置软件为监视器测量的任何值设置警报级别，并为监视器测量的任意两个值设置危险设置点。对于每个测量值，警报可以设置为满量程的 0 到 100%。当满量程范围超过传感器的范围时，设定点受传感器范围的限制
>>>>>型号:3500/42M 近震器/地震监测仪 （4） 通道监视器
【英文介绍】
Features:
(4) Channel monitor
Accepts input from proximity sensors and seismic sensors
Mechanical protection
Provide necessary machine information
The GE/Bently Nevada 3500/42M series of approximation/seismic monitors is a four-channel monitor that accepts input from proximity and seismic sensors, adjusts the signal to provide a variety of vibration and position measurements, and compares the adjusted signal to user-programmable alarms.
You can program each channel with 3500 rack configuration software to perform the following functions: radial vibration, thrust position, differential expansion, eccentricity, REBAM, acceleration, speed, absolute axis, and circular acceptance area.
The main purpose of the 3500/42M proximity/seismic monitor is to provide mechanical protection by continuously comparing the monitoring parameters to the configured alarm Settings to drive the alarm. These modules also provide necessary machine information for operation and maintenance personnel.
The monitoring channels are set up in pairs and can perform up to two specified functions simultaneously. For example, channels 1 and 2 May perform one function, while channels 3 and 4 perform another or the same function.
Proximitor Seismic Monitor protects machinery by comparing monitoring parameters in real time with selected alarm setting points and triggering alarms. It informs operations and maintenance personnel of information about critical machine information.
According to the arrangement, each channel usually adjusts its input signal to produce a set of static values. You can create an alert setting point for any current static value, and you can set a danger setting point for any two of them.
Use the rack configuration software to set an alarm level for any value measured by the monitor and a danger setting point for any two values measured by the monitor. For each measurement, the alarm can be set to 0 to 100% of the full scale. When the full scale range exceeds the range of the sensor, the set point is limited by the range of the sensor
