>>>>>型号:5SHX1445H0002 3BHL000387P0101 驱动板模块
【功能描述】
5SHX1445H0002 3BHL000387P0101 驱动板模块
5SHX1445H0002 IGBT系列高频驱动板，主要采用SG3525A作为PWM脉冲形成,
输出脉冲频率范围20KHZ–60KHZ,脉冲间隔互为180度,死区时间可以自行调整。
5SHX1445H0002可适用于IGBT全桥逆变串联谐振感应加热装置调频调功。功率范围:10KW–1 20KW,该控制板接线少,控制集中,没有调试,
工作电源电压为三路交流双18V/1A及四个22V/0.5A的电源。
5SHX1445H0002具有过流，过压,却水,多种状态指示,并提供开关型霍尔保护接口和线性霍尔保护接口,有全桥逆变IGBT驱动电路,此板可
直接组装IGBT高频感应加热装置。
>>>>>型号:5SHX1445H0002 3BHL000387P0101 驱动板模块
【英文介绍】
5SHX1445H0002 3BHL000387P0101 driver module
5SHX1445H0002 IGBT series high frequency driver board, mainly using SG3525A as PWM pulse formation,
The output pulse frequency range is 20Khz-60khz, the pulse interval is 180 degrees each other, and the dead time can be adjusted by itself.
5SHX1445H0002 can be applied to frequency and power regulation of IGBT full-bridge inverter series resonant induction heating device. Power range :
10KW - 1 20KW, the control board wiring is less, centralized control, no debugging, the working power supply voltage is three AC double 18V/1A and
four 22V/0.5A power supply.
5SHX1445H0002 has over current, over voltage, but water, a variety of state indicators, and provides switching type Hall protection interface and linear
Hall protection interface, a full bridge inverter IGBT drive circuit, this board can be directly assembled IGBT high frequency induction heating device.
